Summary of Contents for Sovereign A041010
- Page 1 450W Electric Hedge Trimmer Item No. 577185 Model No. A041010 INSTRUCTION MANUAL Please read these instructions fully before starting assembly. HHGL Limited, MK9 1BA; HHGL (ROI) Limited, D02 X576 Jan 21...
-
Page 2: Table Of Contents
CONTENTS General safety warnings Intended use Warning symbols In the box Assembly Operation Maintenance and storage Troubleshooting Technical data Warranty... -
Page 3: General Safety Warnings
GENERAL SAFETY WARNINGS SAFETY WARNINGS WARNING! Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. WARNING! Read all safety warnings and instructions designated by the symbol. Save all warnings and instructions for future reference. - Page 4 1. WORK AREA SAFETY a) Keep work area clean and well lit. Cluttered or dark areas invite accidents. b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
- Page 5 e) When operating a power tool outdoors, use an extension cable suitable for outdoor use. Use of a cable suitable for outdoor use reduces the risk of electric shock. f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply.
- Page 6 may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts.
- Page 7 binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools. f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
-
Page 8: Intended Use
the cutter blade stopped. When transporting or storing the hedge trimmer always fit the cutting device cover. Proper handling of the hedge trimmer will reduce possible personal injury from the cutter blades. 3. Keep cable away from cutting area. During operation the cable may be hidden in shrubs and can be accidentally cut by the blade. - Page 9 gardens, parks, sports centres or at roadsides, as well as for agriculture or forestry. Use in any other way is considered contrary to the intended use. Compliance with the operation, service and repair (as specified in this instruction manual) also constitutes essential elements of the intended use.
-
Page 10: Warning Symbols
WARNING SYMBOLS Before any use, refer to the corresponding paragraph in the present manual. Warning! This symbol, before a safety comment, indicates a precaution, a warning or a danger. Ignoring this warning could lead to an accident for yourself or for others. To limit the risk of injury, fire, or electrocution, always apply the recommendations indicated. - Page 11 class II tool Recycle unwanted materials instead of disposing of them as household waste. All tools, hoses and packaging should be sorted, taken to the local recycling centre and disposed of in an environmentally safe way. Guaranteed sound power level data (104dB), in accordance with Directive 2000/14/EC.
-
Page 12: In The Box
IN THE BOX PARTS A. Blade sheath B. Blade C. Safety hand guard D. Front handle E. Rear handle Cable holder G. Cable and plug H. ON/OFF switch Safety switch... -
Page 13: Assembly
ASSEMBLY WARNING! Always take care when removing the packaging to prevent damage to you or to the hedge trimmer. Make sure that you have sufficient space to put the hedge trimmer down. Keep your feet apart so that you have a stable position;... -
Page 14: Operation
OPERATION PREPARE TO OPERATE Warning! Before switching 'ON', make sure that all personnel, particularly children and domestic animals, are at a safe distance. Inspect the hedge to be trimmed, and make sure there are no obstacles or foreign objects in the work area. If any parts are missing, damaged or broken, do not operate your hedge trimmer until all damaged parts have been replaced or repaired. - Page 15 SWITCH OFF To switch the hedge trimmer 'OFF', release either the safety switch or the ON/OFF switch. TRIMMING HEDGE Warning! Before using this hedge trimmer, make sure that you have read all of the safety instructions. Be aware of the position of the cable at all times. Keep it away from the blade.
-
Page 16: Maintenance And Storage
Note: Evergreen hedges and shrubs that retain their leaves in the winter, should be trimmed in April and August. Conifers and other fast-growing shrubs can be trimmed every six weeks from May onwards, throughout the growing season. MAINTENANCE AND STORAGE WARNING! Before cleaning, inspecting or repairing your power tool, make sure the switch is 'OFF'. - Page 17 1. Never use water or chemical cleaners to clean your power tool. Wipe clean with a dry cloth. 2. Always check the cutting head and guard before each use. 3. Always store your power tool in a safe, dry place. 4.
- Page 18 Note: If a moulded plug is fitted and has to be removed, take great care in disposing of the plug and severed cable; it must be destroyed to prevent engaging into a socket. MAINTENANCE For easier operation and longer life, lubricate the cutting blades before and after each use.
- Page 19 STORAGE IMPORTANT! Make sure that the hedge trimmer has been thoroughly cleaned before storing it in a clean, dry and safe place, out of the reach of children. Always fit the transportation blade guard when storing the hedge trimmer. 1. Switch the product 'OFF' and disconnect it from the power supply before transporting it anywhere.
-
Page 20: Troubleshooting
TROUBLESHOOTING WARNING! Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by an authorised service centre or a similarly qualified specialist, if you cannot solve the problem yourself! The following table provides solutions to common problems encountered with the hedge trimmer: Problem Possible cause... -
Page 21: Technical Data
TECHNICAL DATA Model no. A041010 Rated voltage AC 220-240V; 50Hz Input power 450W No load speed 3800min Cutting length 380mm Tooth gap 18mm Protection class II / Machine weight 2.5kg NOISE AND VIBRATION DATA A weighted sound 89.9dB(A), k=3dB(A) pressure(LpA) A weighted sound power 100.9dB(A), k=3dB(A) - Page 22 values can differ from the declared total! Adopt proper measures to protect yourself against vibration exposures! Take the whole work process into consideration, including times the product is running under no load or switched off! Proper measures include, among others, regular maintenance and care of the product and cutting attachments, keeping hands warm, periodical breaks and proper planning of work processes!
-
Page 23: Warranty
Warranty This product is covered by a 1 year warranty. The warranty covers any manufacturing defect in materials, workmanship and finish. Any claim under this warranty must be made by going to your nearest Homebase store, taking your proof of purchase with you, and claims must be made within 1 year of the date of purchase.
