SERVICE MANUAL
Colour Television
The above models are classified as either green products (*1) or non-green products. Green product(s) are
indicated by an underlined serial number. This Service Manual describes replacement parts for green
product(s). When repairing any green product(s), use the parts described in this manual and lead-free solder
(*2).
For (*1) and (*2), see the next page.
Use this Service Manual in conjunction with the original Service Manual (File No. 020-200513) for 27HL95.
© TOSHIBA SINGAPORE PTE LTD
27HL95
FILE NO. 023-2006059GR
SUPPLEMENT
Pubished in Singapore Feb. 2005 Green
Advertisement
Related Manuals for Toshiba 27HL95
Summary of Contents for Toshiba 27HL95
- Page 1 When repairing any green product(s), use the parts described in this manual and lead-free solder (*2). For (*1) and (*2), see the next page. Use this Service Manual in conjunction with the original Service Manual (File No. 020-200513) for 27HL95. Pubished in Singapore Feb. 2005 Green © TOSHIBA SINGAPORE PTE LTD...
-
Page 2: Green Product Procurement
Hazardous Substances. From July 1, 2006, the RoHS Directive will prohibit any marketing of new products containing restricted substances. Increasing attention is given to issues related to the global environmental. Toshiba Corporation recognizes environmental protection as a key management tasks, and is doing its utmost to enhance and improve the quality and scope of its environmental activities. -
Page 3: Chassis And Cabinet Replacement Parts List
• The PC board assembly with mark is no longer available after the end of the production. • The green parts describes in "G" mark, listed to the left side of the Parts No. item. Model : 27HL95 Capacitors..... Ceramic Disk... - Page 4 Location Parts No. Description Location Parts No. Description C677 76797100 CAPACITOR, ELECTROLYTIC, 50V 10UF M CB38 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z C678 76503041 CAPACITOR, PLASTIC FILM , 63V 0.1UF J CE04 76092281 CAPACITOR, CERAMIC DISC, AC250V E 4700PF C678 76503041 CAPACITOR, PLASTIC FILM , 63V 0.1UF J CE05...
- Page 5 Location Parts No. Description Location Parts No. Description GR04 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R6601 76011223 RESISTOR, CHIP, 1/20W 22K OHM J GR05 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R6602 76011103 RESISTOR, CHIP, 1/20W 10K OHM J GR100 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R6602 76011103 RESISTOR, CHIP, 1/20W 10K OHM J GR112...
- Page 6 Location Parts No. Description Location Parts No. Description R6648 76011100 RESISTOR, CHIP, 1/20W 10 OHM J R852 76011471 RESISTOR, CHIP, 1/20W 470 OHM J R6649 76011563 RESISTOR, CHIP, 1/20W 56K OHM J R853 76011103 RESISTOR, CHIP, 1/20W 10K OHM J R6649 76011563 RESISTOR, CHIP, 1/20W 56K OHM J R854...
- Page 7 Location Parts No. Description Location Parts No. Description RE56 76190012 RESISTOR, METAL FILM CHIP 1/16W 1.5K F RV41 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RE57 76190012 RESISTOR, METAL FILM CHIP 1/16W 1.5K F RV42 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RE58 76190013 RESISTOR, CHIP RES 1/16W 22K F RV42 76000445 RESISTOR, CHIP JUMPER, 1608TYPE...
- Page 8 Location Parts No. Description Location Parts No. Description L152 23103828 INDUCTOR, BEAD, TEM2121M DA06 23362042 DIODE, ZENER, UDZS6.8B L921 75001248 CHIP BEADS INDUCTOR DA06 23362042 DIODE, ZENER, UDZS6.8B L921 75001248 CHIP BEADS INDUCTOR DA07 23362042 DIODE, ZENER, UDZS6.8B L922 75001248 CHIP BEADS INDUCTOR DA07 23362042 DIODE, ZENER, UDZS6.8B L922...
- Page 9 Location Parts No. Description Location Parts No. Description SOF3 23340044 SEINE SOFT VER.0.4.5, IC18 QE94 23205442 TRANSISTOR, 2SC3852 SOF3 23340044 SEINE SOFT VER.0.4.5, IC18 QE94 23205442 TRANSISTOR, 2SC3852 SOF3 23340044 SEINE SOFT VER.0.4.5, IC18 QE94 23205292 TRANSISTOR, 2SD2396 SOF3 23340044 SEINE SOFT VER.0.4.5, IC18 QE94 23205292 TRANSISTOR, 2SD2396...
- Page 10 Location Parts No. Description Location Parts No. Description FE72 23144251 FUSE, AXIAL, 125V 1A P812A 23713910 CONNECTOR, CONNECTOR B5P-VH(LF) FE72 23144708 FUSE, AXIAL, 125V 1A PJ22 23757180 CONNECTOR, FH12-50S-0.5SV(55) FH12-50S-0.5SV(55) FE73 23144227 FUSE, CARTRIDGE 5.2X20, 125V 5A PJ60 23757180 CONNECTOR, FH12-50S-0.5SV(55) FH12-50S-0.5SV(55) FE73 23144715 FUSE, CARTRIDGE 5.2X20, 125V 5A PJ22...
- Page 11 H003E 23748093 WASHER, WASHER WAVE15X10.6X0.2 32HL95;D055098E E871B 23960136 ADHESIVE, SILICONE, TSE3843-W A703 23945143 BAG, PROTECTIVE A703 23945190 BAG, PROTECTIVE, 26WL36 A701A 23015140 CARTON, CASE 27HL95 27HL95;S1305D062 A315 23533375 COVER, BACK CENTER COVER 27HL85;Z045079E A401 23533330 COVER, BACK COVER 27WL55A;A045387E A445 23533610 COVER, CABLE COVER BOTTOM ASSY 27WL55A;A055117E...
- Page 12 TOSHIBA SINGAPORE PTE. LTD. Blk438B ALEXANDRA ROAD #06-05 ALEXANDRA TECHNOPARK...
