Summary of Contents for Jacto Condorito
- Page 1 105 Gal 30’ 3 point mounted Boom Sprayer 105 Gal. 30 3 point mounted Boom Sprayer...
- Page 2 Condorito arrives in three crates Unit (left) Unit (left) Booms (Left, Right & Center) 53” x 42” x 45” 333 lbs Center spray boom support section 80” x 7” x 29” 60 lbs Total shipping weight 477 lbs...
- Page 3 When removing the unit from the shipping crate, be cautious of some crate boards going through the unit chassis. Use a Crow Bar to to Dismantle crates.
- Page 4 Remove the Control Valve from it’s shipping position (on the chassis just above the filter). Move it around to the front of the unit front of the unit Mount it with the two Mount it with the two (2) 5/16” bolts, lock washers &...
- Page 5 Connect the Bypass Hose from the control valve to the top of the main tank.
- Page 6 Select the height of the sprayer boom by attaching the center boom support section to the boom support section to the corresponding bolt holes on the rear of the chassis. Attach the center support section using the four (4) 3/8” the four (4) 3/8 bolts, washers, and nuts, which...
- Page 7 The center The center boom section attaches to th b the boom support section with four (4) bolts, washers, and nuts which nuts which should be on the center boom section boom section when unpacking.
- Page 8 We recommend We recommend using zip ties to anchor the hose to the t th boom support. Route the two (2) chemical hoses from the control valve across the top of the tank, and connect to each respective half of the chemical circuit on the center respective half of the chemical circuit on the center section.
- Page 9 Each boom will be labeled Left or Right...
- Page 10 Position each boom onto the post of the center section and attach using the following configuration section and attach using the following configuration. C tt Cotter Pin Two (2) small washers Boom Stabilizer St bili Four (4) small washers Two (2) nuts, tighten the first nut snuggly, the second nut is to...
- Page 11 Connect chemical hoses from each boom each boom section to the ends of the center section. Tighten using the hose clamp. Fold over the outer boom segment, then rotate the boom backward and up to the rotate the boom backward and up to the mounting...
- Page 12 Fold each boom up to lock into boom support mount. If the posts do not align correctly adjust the boom’s locking piece do not align correctly, adjust the boom s locking piece. (To adjust th h l the hole position to mate smoothly smoothly...
- Page 13 Cut the two (2) zip ties holding the pump to the side of the chassis. The Safety Chain affixed to the affixed to the pump should be attached to the chassis side to chassis side to prevent the pump from knocking around.
- Page 14 Affix the twenty-one Affix the twenty-one (21) nozzles to the boom. Connect the Connect the Condorito sprayer to the tractor’s three-point three point suspension (See pages 20 – 24 of the Operator’s Manual).
