Specifications - ICS Linker IIa User Manual

SUPPLY VOLTAGE
IDLE CURRENT
MAXIMUM CURRENT TX 1 OUTPUT
MAXIMUM CURRENT ON AUXILIARY 1 OUTPUT
MAXIMUM CURRENT ON AUXILIARY 2 OUTPUT
MAXIMUM CURRENT ON AUXILIARY 3 OUTPUT
VOLTAGE IN ON RECEIVER 1 AUDIO INPUT
VOLTAGE IN ON RECEIVER 1 AUDIO INPUT
VOLTAGE IN ON RECEIVER 2 AUDIO INPUT
VOLTAGE IN ON THE CONTROL RECEIVER AUDIO INPUT
MAX VOLTAGE OUT ON RECEIVER 1 AUDIO OUTPUT
MAX VOLTAGE OUT ON RECEIVER 2 AUDIO OUTPUT
VOLTAGE IN ON THE RX 1 COS
VOLTAGE IN ON THE RX 2 COS
VOLTAGE IN ON THE CONTROL RX COS
VOLTAGE IN ON THE RX 1 CTCSS
VOLTAGE IN ON THE RX 2 CTCSS
OUTPUT IMPEDANCE FOR TRANSMITTER 1 AUDIO OUTPUT < 300 ohms
OUTPUT IMPEDANCE FOR TRANSMITTER 2 AUDIO OUTPUT < 300 ohms
INPUT IMPEDANCE ON RECEIVER 1 AUDIO INPUT
INPUT IMPEDANCE ON RECEIVER 2 AUDIO INPUT

SPECIFICATIONS

10
13.8V
@13.8V 29mA LEDs disabled
1 A
1 A
1 A
1 A
20mVpp to 10Vpp
20mVpp to 9Vpp
20mVpp to 9Vpp
20mVpp to 9Vpp
9Vpp
9Vpp
0 to 30V 1 to 9V readable
0 to 30V 1 to 9V readable
0 to 30V 1 to 9V readable
0 to 30V 1 to 9V readable
0 to 30V 1 to 9V readable
~100K ohms
~100K ohms
