© 2012 Char-Broil, LLC Columbus, GA 31902
PRODUCT GUIDE
MODEL 465272312
Char-Broil Performance T-22G
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
Printed in China
See rating label on grill for serial number.
Assembly instructions © 2012
10/18/12 • 80021066

Advertisement

loading
Need help?

Need help?

Do you have a question about the 465272312 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Char-Broil 465272312

Summary of Contents for Char-Broil 465272312

  • Page 1 Char-Broil Performance T-22G IMPORTANT: Fill out the product record information below. Serial Number See rating label on grill for serial number. Date Purchased Assembly instructions © 2012 © 2012 Char-Broil, LLC Columbus, GA 31902 10/18/12 • 80021066 Printed in China...

  • Page 2: Table Of Contents

    DANGER TABLE OF CONTENTS For Your Safety ........2-3 If you smell gas: Grilling Guide.
  • Page 3 Installation Safety Precautions CAUTION Use grill, as purchased, only with LP (propane) gas. Using pots larger than 6 quarts in capacity could Gas Cylinder exceed weight limit of the The gas tank must have a vapor extraction device side burner shelf and come with a collar to protect the valve.
  • Page 4 GRILLING GUIDE – Getting Started GRILLING GUIDE – Grilling 101 Outdoor grilling is really quite simple. You'll succeed with First Time Use burgers, dogs, or steaks usually on your very first try. With Read your Assembly Manual and ensure the grill is put together experience, you will learn how to work with your grill, creating properly.
  • Page 5 Rotisserie Cooking GRILLING GUIDE – Tips & Tricks Rotisserie cooking is best for 'round' meat, such as large roasts, whole poultry, and pork. It generally requires an accessory motor Cooking on your new grill is a hands-on experience, and it is and spit rod that allows the meat to be turned at a constant recommended to remain outside with your grill while cooking.
  • Page 6 Wood Chips For extra smoke flavor when grilling, try adding wood chips. Soak the chips in water for approximately 30 minutes before adding to a smoke box or pan. Place smoke box or pan on top of the cooking grate above the flame. Turn grill on high until the wood starts to smoke.
  • Page 7 Cooking surfaces: If a bristle brush is used to clean any of the GRILLING GUIDE – Cleaning Your Grill grill cooking surfaces, ensure no loose bristles remain on cooking Why Clean? surfaces prior to grilling. It is not recommended to clean cooking We've all heard the saying 'An ounce of prevention is worth a surfaces while grill is hot.

  • Page 8: For Your Safety

    LP Cylinder Leak Test For your safety •Leak test must be repeated each time LP cylinder is exchanged DANGER or refilled. •Do not smoke during leak test. •Do not use an open flame to check for gas leaks. • NEVER store a spare LP cylinder under or near •Grill must be leak tested outdoors in a well-ventilated area, away from ignition sources such as gas fired or electrical the appliance or in an enclosed area.
  • Page 9 Push and hold ELECTRONIC IGNITION button until the burner lights.

  • Page 12: Parts List

    PARTS LIST Qty Description Qty Description TOP LID CART RIGHT SIDE PANEL BOTTOM SHELF HANDLE F/ TOP LID CASTER, LOCKING LOGO PLATE CASTER, FIXED RUBBER BUMPER, RECTANGLE, F/ TOP LID HARDWARE F/ TOP LID ASSEMBLY FIREBOX RUBBER BUMPER, LID COOKING GRATE WARMING RACK NOT Pictured FLAME CARRYOVER TUBE W/ COTTER PIN...

  • Page 13: Parts Diagram

    PARTS DIAGRAM...

  • Page 14: Assembly

    ASSEMBLY Place bottom shelf upside down. Insert Caster Pin into the caster mounting plate to lock it in place, shown A. Spin the caster clockwise into the threads on the bottom shelf until secure. Remove the Caster Pin and repeat for remaining casters.
  • Page 15 This step requires two people to lift and position grill head on to cart. Carefully lower the grill head onto the cart, aligning slots at bottom of grill head with posts on cart side panels, shown A. Install universal barb to the connector under grill head, shown B. Connector Grill head Right side panel...
  • Page 16 Pull out the two knobs from control panel. Insert temperature gauge stem into the bigger hole above knob bezel, shown A. Make sure the gauge is pushed in as far as it will go, then push the gauge downward until it clips into the panel, shown B/C. Re-install the two knobs.
  • Page 17 Attach foldable side shelf brackets to the tracks under right side shelf using one shoulder screw, 7mm flat washer, 7mm lock washer and 1/4” nut each side, shown A/B. Pull foldable side shelf outward and press it down, shown C. Push foldable side shelf toward right side shelf untill they gather up, shown D.
  • Page 18 Insert flange on right side shelf into side shelf brackets on side of firebox, shown A. Attach right side shelf using three 1/4”-20x3/4” screws, 7mm flat washers, 7mm lock washers and 1/4” nuts, shown B. Attach rear of shelf using one 1/4-20x1½” screw, 7mm lock washer, and 7mm flat washer in lower hole, shown C. Attach front of shelf and fascia using one #8x3/8”...
  • Page 19 Insert front brace under control panel and between cart side panels. Make sure door hinge pins are on the top side and facing the front. Secure using two 1/4-20x1½” screws, 7mm lock washers, and 7mm flat washers on each side. NOTE: MAKE SURE THAT THE FRONT BRACE IS MOUNTED IN THE MOST DOWNWARD POSITION WHEN ASSEMBLED TO CART.
  • Page 20 Insert hinge pin on bottom of door into hole in bottom shelf. Press upper hinge pin in front brace, align hinge hole on top of door, and release hinge pin into door. PRESS Top of door Door Hinge pin on bottom of door Release the cap and nut from electronic ignition module.
  • Page 21 Install flame tamers by sliding one end of each flame tamer into slots at front of firebox and resting opposite end on pins in back of firebox. Front of firebox Flame tamers Back of firebox Place cooking grates onto the firebox as shown. Insert the two wire ends at rear of warming rack into holes in back of firebox.
  • Page 22 On back of grill, slide grease tray into opening in upper back panel. CAUTION Failure to install grease tray will cause hot grease to drip from bottom of grill with risk of fire or property damage. Grease tray Unscrew electronic ignition cap on cart right side panel. Insert AA battery into ignitor, negative (—) end first. Replace the cap.
  • Page 23 Your grill does not come with the regulator and hose connected. To connect you must do the following. Connect one end of hose to valve , and then screw clamp tight, then repeat the same process with gas regulator. Shield Shield ALWAYS CHECK THE CONNECTIONS FOR LEAKS BEFORE LIGHTING THE GRILL...

  • Page 24: Troubleshooting

    DANGER: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Prevention/Solution Gas leaking from •Damaged hose. •Turn off gas at LP cylinder or at source on natural gas systems. If cracked/cut/burned anything but burned, replace valve/hose/regulator.
  • Page 25 Troubleshooting (continued) Problem Possible Cause Prevention/Solution Burner(s) will not light PIEZO PUSH-BUTTON AND ROTARY: using ignitor. •Push-button sticks at bottom. •Replace ignitor. •Rotary knob rotates without clicking. •Replace knob. •Sparking between ignitor and electrode. •Inspect wire insulation and proper connection. Replace wires if insulation is broken.
  • Page 26 Troubleshooting - Electronic Ignition Problem (Ignition) Possible Cause Check Procedure Prevention/Solution SECTION I No sparks appear at • Battery not installed • Check battery orientation. • Install battery (make sure that “+” and “–” any electrodes when properly. connectors are oriented correctly, with “+” end up Electronic Ignition Button and “–”...

  • Page 27: Limited Warranty

    The collection and delivery of your product, unless local regulations specify otherwise in which case local regulations will override this. In markets where there is no distributor or an authorized reseller Char-Broil consumers bear these costs themselves. 7. Repairs to parts or systems resulting from unauthorized modifications made to the product.
  • Page 28 Authorized Distributors List If you have a question or need help during assembly, call: Chile Colombia ZAPFSA Bar BQ Center Ltda Calle 12 # 30-126 OFC 102 Av. Las Condes 7633 Edificio Blux Las Condes, Santiago, CHILE Medellin-Colombia Tlf. 562 245 4878 Tlf 574-448-0451 / 316-4860 Correo: bbq@barbecuecenter.cl Fax 574-268-7130...
