2500645
Please read all instructions carefully before
use and retain for future reference.
ATTENTION This appliance has a thermal
cut out switch. The thermal cut out will
activate and shut down the appliance
should the appliance overheat.
Unplug from the mains and or battery and
allow to cool for 30 minutes before re-use.
CAUTION Do not immerse in water.
CAUTION hot surfaces
Do not cover.
Do not use outdoors.
THIS PRODUCT IS ONLY SUITABLE FOR WELL INSULATED SPACES OR
A5P | 01
OCCASIONAL USE.
Advertisement
Table of Contents
Related Manuals for VonHaus 2500645
Summary of Contents for VonHaus 2500645
- Page 1 2500645 Please read all instructions carefully before use and retain for future reference. ATTENTION This appliance has a thermal cut out switch. The thermal cut out will activate and shut down the appliance should the appliance overheat. Unplug from the mains and or battery and allow to cool for 30 minutes before re-use.
- Page 2 Ground Fault Indicator (US). Do not use with a damaged cable or plug. If the supply cable is damaged, it must be replaced by a qualified engineer or Please read all instructions carefully authorised service agent in order to avoid before use and retain for future reference.
- Page 3 Never operate the appliance when empty. Do not overload/overfill the appliance. When using for the first time your appli- ance may give off a ‘new’ smell or vapour. This will dissipate after a few uses. Do not lift or move the appliance whilst in use. Do not operate continuously for periods longer than those marked on the product or indicated in the instructions.
- Page 4 INFORMATION REQUIRMENTS FOR ELECTRICAL LOCAL SPACE HEATER Model 2500645 Item Symbol Value Unit Item Unit Type of heat input for Electrical Storage Heaters Heat Output only (select one) Nominal Heat Manual heat charge control with Output integrated thermostat. Minimum Heat...
-
Page 5: Specification
SPECIFICATION 1- Radiator Fins 2- Adjustable Thermostat. 3- Power Switch 4- Front handle 5- Timer. 6- Cable Holder 7- Wheel Base 8 - Wheels A5P | 01... - Page 6 ASSEMBLY Turn the radiator upside-down on a scratch-free and stable surface to prevent damage to the paint finish or your floor (see Fig 1) surfacing Fit the wheels assemblies onto the radiator by placing the U-shaped bolts between the outermost fins on each side (see Fig.2 - 4).
-
Page 7: Operation
OPERATION Place the Unit in an upright position Turn the Thermostat Dial clockwise on a flat, steady, stable, heat-resistant to the ‘‘III’’ position. When the room surface. Make sure there is nothing temperature rises to a comfortable level, flammable or heat sensitive within 1 meter slowly turn thermostat counter-clockwise (40 inches). - Page 8 TIMER SETTING OPERATION NOTE: This is a 24 hours timer. There are 96 segments, each segment represents 15 mins. Firstly, turn the clock “A” clockwise to align with arrow “B” to match the current time Segments which are pushed outwards will represent the time where the heater will be turned ON.
-
Page 9: Safety Features
SAFETY FEATURES This Radiator is fitted with an overheat a thermostatic safety device. The safety protection switch (thermal cut-out) which device will activate and cut out the power will power off the appliance automatically to the Radiator once a certain temperature in case of overheating. - Page 10 Check with support@domu.co.uk your local authority for recycling advice. VonHaus is a registered trademark of DOMU Brands Ltd. Made in China for DOMU CUSTOMER SERVICE If you are having Brands. M24 2RW.
