Step 1; Step 2; Assembly Completion; Hardware & Tool Required - modway Shore EEI-2264 Assembly Instruction

EEI-2264
CORNER

STEP 1:

Remove the plastic covers which pre-install in the end of the Seat Frame (4) by using Allen Wrench (C).
Please put left Leg (2) on a carpeted or padded area.
Insert Top Rail (1) and Seat Frame (4) into Left Leg (2) as shown.
Insert 3 pieces of Bolt (B) from the pre-drilled holes on the bottom of the Top Rail (1) and Seat Frame (4) into each side
on the bottom of Left Leg (2).
Insert 2 pieces of Bolt (A) from the pre-drilled holes on the side rail of the Seat Frame (4) into each end of Left Leg (2) as shown.
Do not fully tighten Bolt (A&B) at this step.
Repeat the same steps for Right Leg (3).
After checking the leveling for all connections, please use Allen Wrench (C) to tighten all Bolts (A&B) clockwise until secure.
The bottom of seat frame and legs
2
3
C
2
B
4
The bottom of seat frame and legs
Ax4 Bx6

STEP 2:

Carefully place the assembled corner at your desired position.
Put the Seat Cushion (5), Back Cushion (6), and Side Cushion (7) to assembled corner frame as shown.
Customer Service 908-368-1025︱www.modwayfurniture.com
A C
2
4
Cx1
7
Assembly is completed. The corner is ready to enjoy now!
1
The bottom of top rail and legs
3
6
5
2
C
B
1
Hardware & Tool required
Page 2 of 2
