ZP18
ZOOM LED PAR CAN
Item ref: 154.018UK
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZP18 and is the answer not in the manual?

Questions and answers

Related Manuals for Qtx ZP18

Summary of Contents for Qtx ZP18

  • Page 1 ZP18 ZOOM LED PAR CAN Item ref: 154.018UK User Manual...
  • Page 2 To prevent risk of fire or electric shock, do not expose electrical parts to rain or moisture. If any liquids are spilled on the ZP18, allow it to dry out and have it checked by qualified service personnel before further use.

  • Page 3: Rear Panel

    Placement The ZP18 has a built-in dual “U” bracket, which can allow the can to be free standing or fixed to trussing. If free standing, ensure that the ZP18 is positioned on a stable, non-slip surface. If mounted at height onto a truss or stand, it is advised to use a drop wire for additional safety.
  • Page 4 Onboard Menu The various modes of operation of the ZP18 can be set using the control panel (2) and digital LED display (3) MODE ENTER Function UP/DOWN ENTER 000-255 Green 000-255 Blue 000-255 STAT White 000-255 Strobe 000-255 Zoom 000-255...

  • Page 5: Dmx Operation

    DMX operation If the ZP18 is to be operated by DMX512, connect the signal from the controller to the DMX input XLR (1). Continue the DMX signal onto further lighting fixtures from the DMX output XLR (5) To control from DMX512, it is necessary to set the DMX start address via the control panel and display (2 & 3) Press the MENU button until the display shows “dMX”, then press the ENTER button.
  • Page 6 HSV mode Value Function 000-255 Hue (colour) 000-255 Saturation (0-100%) 000-255 Value (brightness) 000-255 Zoom 000-255 Zoom speed (slow to fast) ARC.1 mode Value Function 000-255 000-255 Green 000-255 Blue 000-255 Zoom 000-255 Zoom speed (slow to fast) AR1.d mode Value Function 000-255...
  • Page 7 The RGBW values of these white shades can be adjusted in the CAL1 calibration menu. Programming User Sequences PR01-PR10 are user sequences that can be programmed in the EDIT menu and stored onboard the ZP18. Press MENU until EDIT is displayed and select the program to be edited.

  • Page 8: Specifications

    Master/Slave Operation Connect a DMX lead from a standalone ZP18 unit to further slave units and set each slave to “SLAV” in the RUN menu. The slave units will now mimic the standalone “master” ZP18 fixture. Passcode Key and SET menu functions The KEY setting in the menu sets a lock for the display.

This manual is also suitable for:

154.018uk
