GE GTS18XCS Dimensions And Installation Information

GTS18XCS
GE 18.2 Cu. Ft. Top-Freezer Refrigerator
®
Dimensions and Installation Information
Height to top of hinge (in.) A
Height to top of case (in.) B
Case depth without door (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
Depth with fresh food door open 90° (in.) F
Width (in.) G
Width with door open 90° with door handle (in.) H
Each side (in.)
Top (in.)
Back (in.)
* H e g i t h o t m d i f - e r z e r e n i ( : ) . 53-15/16
For answers to your Monogram,
®
GE appliance questions, visit our website at
®
ge.com or call GE Answer Center
®
800.626.2000.
66-5/8
66-1/8*
27-1/2
30-1/4
32-1/8
58-1/8
29-1/2
32
1/8
1
1
GE Profile or
™
service,
Front View
A B
Top View
C
D
Dimension and installation information are shown in inches.
R
Specification Created 12/09
H
G
E
F
Listed by
Underwriters
Laboratories
R
310355
