- Page 1 ASSEMBLY INSTRUCTIONS Description : X-SIDE WINE RACK 30X36 Item No. : WR-3036X ITEM NO.: WR-3036X Printed in Vietnam ISSUED JAN 22, 2018 - 1 -...
-
Page 2: Before Assembly
Protect the surface of the product with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: WR-3036X Printed in Vietnam ISSUED JAN 22, 2018 - 2 -... -
Page 3: Part List
(ɸ6.5 x 13mm) Lock Washer Long Screw (ɸ6.5 x 11mm) (M4 x 35mm) Short Screw Steel band (M3.5 x 15mm) Allen key (M4 x 30mm x 110mm) ITEM NO.: WR-3036X Printed in Vietnam ISSUED JAN 22, 2018 - 3 -... - Page 4 Attach top (A) to side frame (B) with bolts (1), and washers (3) and (2) as shown below. Tighten with Allen key (7). STEP 2 Attach racks (C) and (D) to side frame (B) with screws (4) as shown below. Tighten with a screwdriver. ITEM NO.: WR-3036X Printed in Vietnam ISSUED JAN 22, 2018 - 4 -...
- Page 5 Attach steel band (6) to the unit with short screws (5) and attach the steel band to the wall with long screws (4) as shown below (to secure the product and prevent tipping). Tighten with a screwdriver. ITEM NO.: WR-3036X Printed in Vietnam...
