INSTRUCTION
MANUAL
Model: C-1368-1B
aofis.service@gmail.com
(909)637-7665 | (909)637-7593

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-1368-1B and is the answer not in the manual?

Questions and answers

Summary of Contents for HOMEDEPOT C-1368-1B

  • Page 1 INSTRUCTION MANUAL Model: C-1368-1B aofis.service@gmail.com (909)637-7665 | (909)637-7593...
  • Page 2: Assembly Guide

    aofis.service@gmail.com (909)637-7665 | (909)637-7593 ASSEMBLY GUIDE Congratulations, you are now the owner of a brand new home & office chair! To best enjoy the comfort of the chair, you have to put it together first! This assembly guide will take you through the assembly process. To make sure the assembly goes well, please follow the instructions, and especially the important safety information.
  • Page 3: Package List

    aofis.service@gmail.com (909)637-7665 | (909)637-7593 Package List Without further ado, we kindly suggest you to list all parts needed for the chair first. *1(L)*1(R) (1)*1 (2)*1 Backrest Seat Cushion Armrests (4)*1 (5)*1 (6)*1 Mechanism Gas Lift Base (7)*5 (8)*5 (9)*10 Legs Casters Bolts (10)*4...
  • Page 4: Assembly Instruction

    aofis.service@gmail.com (909)637-7665 | (909)637-7593 Assembly Instruction Step 1: (9)×2 Turn the Base (6) upside down, then insert Base Legs (7) one by one to Base. Use the Wrench (13) to screw Ten Bolts (9) into the pre-drilled screw holes to fix the Base and the Base Legs.
  • Page 5 aofis.service@gmail.com (909)637-7665 | (909)637-7593 (12)×6 Step 4: Turn the Seat Cushion (2) upside down and align the hole position of the Armrest (3)*1(L)*1(R) with the pre-drilled hole position under the Seat Cushion. Attach the Armrest (3)*1(L)*1(R) to the Seat Cushion (2) with Six Bolts (12), using the Wrench (13).
  • Page 6 aofis.service@gmail.com (909)637-7665 | (909)637-7593 Step 6: Insert the slot on the back of the mechanism behind the cushion into the Gas Lift. Step 7: This is to fix the Backrest(1) on the Armrest(3)*1(R), use a Wrench(13) to twist a Screw in(B1) don't tighten the screw(11)*1 tightly.
  • Page 7 aofis.service@gmail.com (909)637-7665 | (909)637-7593 Step 8: This is to fix the Backrest(1) on the Armrest(3)*1(L) use a Wrench(13) to twist a Screw in (B1),don't tighten the screw(11)*1 tightly. Step 9: Use the wrench(13) to make the left and right two screws(11)into (B2), and then tighten all the screws.
  • Page 8 aofis.service@gmail.com (909)637-7665 | (909)637-7593 Instructions For Use 1. Seat Height: Paddle-shaped lever on the right side To raise: While taking your weight off chair, lift lever up. To lower: While seated, lift lever up. * At the proper height, your feet should rest flat on the floor. 2.
  • Page 9 aofis.service@gmail.com (909)637-7665 | (909)637-7593 3. Operating the rocking function To let your chair tilt back, pull the control handle out. To stop your chair from tilting, sit forward, then push the control handle in.
  • Page 10: Safety And Maintenance

    aofis.service@gmail.com (909)637-7665 | (909)637-7593 Safety And Maintenance Do not stand on the chair, Do Not use the chair as a stepladder. Use this product for seating one person at a time. Do not use the chair unless all bolts and screws are firmly secured. Avoid contact with sharp objects to prevent puncturing the fabric.
  • Page 11: Limited Warranty

    aofis.service@gmail.com (909)637-7665 | (909)637-7593 Limited Warranty The producer promises to repair or replace any chair that is found to be defective in material or workmanship within one(1) and year from the date of original purchase so long as you, the original purchaser, still owns it. This is your sole and exclusive remedy.
  • Page 12: Return Policy

    aofis.service@gmail.com (909)637-7665 | (909)637-7593 RETURN POLICY: We adopt a 30 days return policy which means that all products purchased on this website may be returned to us within the timeframe. You need to contact us within 30 days after the product(s) came into your possession and the product(s) must be returned to us without any undue delays.
  • Page 13 aofis.service@gmail.com (909)637-7665 | (909)637-7593...
