- Page 1 INSTRUCTION MANUAL Model: WRCW-1102SET-BN support@vipclub.app 833-969-2075 / 1 (770) 298-8947...
-
Page 2: Assembly Guide
support@vipclub.app 833-969-2075 / 1 (770) 298-8947 ASSEMBLY GUIDE Congratulations, you are now the owner of the new 4 - Piece Rattan Multiple Chairs Seating Group! Before enjoying the set, you have to assemble it. This assembly guide will take you through the basic assembly process. -
Page 3: Package List
support@vipclub.app 833-969-2075 / 1 (770) 298-8947 PACKAGE LIST Without further ado, we kindly suggest you to list all parts needed for the chair first. ①*20 ②*28 Bolt M6 x 30 mm Bolt M6 x 40 mm ③*1 Allen key M4... -
Page 4: Assembly Instruction
support@vipclub.app 833-969-2075 / 1 (770) 298-8947 Assembly Instruction Step 1: Connect (H) and (I) with bolt (1). Tips: Use the Wrench (3) to screw Two Bolts (1) into the pre-drilled screw holes. Step 2: Connect (G) and (H) with One bolt (2). - Page 5 support@vipclub.app 833-969-2075 / 1 (770) 298-8947 Step 3: (1) Align the left Armrest (C) over the pre-drilled holes underneath the Seat Cushion (H). (2) Attach the Armrest (C) to the Seat Cushion using Two Bolts (2). Then the front leg of the Armrest (C) attach to (I) with One bolt (1), tighten all the bolts with the Wrench (3).
- Page 6 support@vipclub.app 833-969-2075 / 1 (770) 298-8947 Step 5: Connect (F) and (J) with two bolt (1). Step 6: Connect (F) and (E) with two bolt (2).
- Page 7 support@vipclub.app 833-969-2075 / 1 (770) 298-8947 Step 7: Refer to step 3 to install the Armrest (C) and (D) of the Loveseat. Step 8: Refer to step 4...
- Page 8 support@vipclub.app 833-969-2075 / 1 (770) 298-8947 Step 9: Use 4 bolt (1) to fix the table legs (B) on one side of the (A). Step 10: Repeat step 9 to complete the installation on the other side of the table.
-
Page 9: Safety And Maintenance
support@vipclub.app 833-969-2075 / 1 (770) 298-8947 Step 11: Put the Glass(M) on the table, and put the Cushion (K) on the two Armchairs, and Cushion(L) on the Loveseat. Finish the installation!! Safety And Maintenance Do not stand on the chair or the table. Do Not use the chair as a stepladder. -
Page 10: Limited Warranty
support@vipclub.app 833-969-2075 / 1 (770) 298-8947 Limited Warranty ONE year limited warranty The producer promises to repair or replace any chair that is found to be defective in material or workmanship within one(1) and year from the date of original purchase so long as you, the original purchaser, still owns it. This is your sole and exclusive remedy. - Page 11 support@vipclub.app 833-969-2075 / 1 (770) 298-8947 RETURN POLICY ： We adopt a 30 days return policy which means that all products purchased on this website may be returned to us within the timeframe. You need to contact us within 30 days after the product(s) came into your possession and the product(s) must be returned to us without any undue delays.
- Page 12 support@vipclub.app 833-969-2075 / 1 (770) 298-8947...
