Rolled arm sofa & loveseat

Advertisement

Quick Links

ROLLED ARM SOFA & LOVESEAT
Seat Deck
A
X1
Hand Bolt
D
X4
B
E
Leg
G
X4
NO TOOLS REQUIRED
Seat Back
X1
Back Pillow
X3 for Sofa
X2 for Loveseat
H
Sofa Arms
C
X2
Seat Cushion
F
X3 for Sofa
X2 for Loveseat
Dust Cover
X1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Brookside BS0004LVS00NV and is the answer not in the manual?

Questions and answers

Summary of Contents for Big Lots Brookside BS0004LVS00NV

  • Page 1 ROLLED ARM SOFA & LOVESEAT Seat Deck Seat Back Sofa Arms Hand Bolt Back Pillow Seat Cushion X3 for Sofa X3 for Sofa X2 for Loveseat X2 for Loveseat Dust Cover NO TOOLS REQUIRED...
  • Page 2 ROLLED ARM SOFA & LOVESEAT 1. Rotate the stretchers on the seat deck (A). 2. Align the sofa arms (C) with the holes and connect the hand bolts (D). Please note that the arms are labeled Left Side Facing Arm (LSF) and Right Side Facing Arm (RSF).
  • Page 3 ROLLED ARM SOFA & LOVESEAT 3. Turn the hand bolts (D) clockwise until slightly loose. 4. Slide down the backrest (B) into the brackets on each arm (C). NOTE: having arms loose help give wiggle to adjust. Tighten the hand bolts (D) to secure the backrest (B) to the arms (C).
  • Page 4 ROLLED ARM SOFA & LOVESEAT 5. Pull down the bottom of the arms (C) and backrest (B) and secure to the seat deck (A) with black adhesive straps. Then place the dust cover (H) onto the straps. 6. Screw in each leg (G) clockwise until secure.
  • Page 5 ROLLED ARM SOFA & LOVESEAT 7. Add the seat cushions (F) and seat backs (E). Congrats! Enjoy your new sofa or loveseat.
  • Page 6 ROLLED ARM SOFA & LOVESEAT LIMITED 1-YEAR WARRANTY WHAT IS COVERED WHAT WE WILL DO This warranty covers any defects in At our sole discretion we will repair, materials or workmanship, with the replace, or refund any product that exceptions stated below. proves to be defective in materials or workmanship.

This manual is also suitable for:

810527176Brookside bs0001lvs00lg810527172Brookside bs0002lvs00lg810527175
