ASSEMBLY INSTRUCTION
E085-05 SOFA TABLE WITH GLASS TOP
A
Side Panel
4pcs
E
Glass Top
1pc
I
Leveler
10mm
6pcs
B
Middle Side Panel
1pc
F
Bolt
1/4" x 5/8"
10pcs
J
Allen Wrench
1/4"
1pc
C
Bottom Frame
1pc
G
Bolt
1/4" x 1/2"
10pcs
This page lists all the contents included in the box.
Please take the time to identify the hardware as
well as the individual components to this product.
As you unpack and prepare for assembly, place
the contents on a carpeted or padded area to
protect them from damage.
1
D
Top Frame
pc
1
H
Glass Pad
8mm
6pcs

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SOFA TABLE WITH GLASS TOP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for overstock SOFA TABLE WITH GLASS TOP

  • Page 1 ASSEMBLY INSTRUCTION E085-05 SOFA TABLE WITH GLASS TOP Side Panel Middle Side Panel Bottom Frame Top Frame 4pcs Glass Top Bolt Bolt Glass Pad 1/4” x 5/8” 1/4” x 1/2” 10pcs 10pcs 6pcs Leveler Allen Wrench 10mm 1/4” 6pcs This page lists all the contents included in the box.
  • Page 2 *** Do not tighten screws & bolts until the entire unit is completely assembled. Attach Side Panel (A) to Bottom Frame (C) by Bolt (F) and Allen Wrench (J) as shown. Attach Side Panel (A) and Middle Side Panel (B) to Bottom Frame (C) by Bolt (F) and Allen Wrench (J) as shown.
  • Page 3 Attach Top Frame (D) to Side Panel (A) and Middle Side Panel (B) by Bolt (G) and Allen Wrench (J) as shown. Attach Leveler (I) to the bottom of Bottom Frame (C). Attach Glass Pad (H) to Top Frame (D), then place Glass Top (E) as shown.
