Keith WALKING FLOOR KICD Owner's/Operator's Manual

Container drive
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
KICD - Container Drive
KEITH Manufacturing Co.
KEITH Manufacturing Co.
www.KeithWalkingFloor.com
www.KeithWalkingFloor.com
World Headquarters
World Headquarters
Toll-Free: 800-547-6161
Toll-Free: 800-547-6161
Phone: +1-541-475-3802
Phone: +1-541-475-3802
Europe Headquarters
Europe Headquarters
Phone: +31-342-422007
Phone: +31-342-422007
OWNER / OPERATOR MANUAL
©2020 KEITH Manufacturing Co. All Rights Reserved. KEITH, KEITH logo and WALKING FLOOR are registered trademarks of KEITH
Manufacturing Co. Equipment manufactured by KEITH Manufacturing Co. is protected by numerous patents both domestic and foreign.
Released 2020-06-30
Original Instructions
Original Instructions
10777601
DOC06387
Rev. C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WALKING FLOOR KICD and is the answer not in the manual?

Questions and answers

Related Manuals for Keith WALKING FLOOR KICD

Summary of Contents for Keith WALKING FLOOR KICD

  • Page 1 Original Instructions Original Instructions ©2020 KEITH Manufacturing Co. All Rights Reserved. KEITH, KEITH logo and WALKING FLOOR are registered trademarks of KEITH Manufacturing Co. Equipment manufactured by KEITH Manufacturing Co. is protected by numerous patents both domestic and foreign. Released 2020-06-30 DOC06387 Rev.

  • Page 2: Table Of Contents

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive Table of Contents Introduction Declaration of Incorporation KEITH ® WALKING FLOOR ® Unloading System Limited Warranty Warranty Registration Card Safety 1.1 General Safety 1.1.1 Intended Function and Expected Use: 1.1.2 Improper Use...
  • Page 3 5.1 Check List 5.2 Problem / Solution - Troubleshooting 5.3 Adjustments & Replacements 5.3.1 Switching Valve Adjustment 5.3.2 Check Valve Replacement 5.3.3 Control Valve & Restrictor Valve Replacement 5.4 Technical Support Contact Information - KEITH Manufacturing Co. DOC06387 Rev. C...

  • Page 4: Introduction

    OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive Introduction We at KEITH Manufacturing Co. are very happy you have decided to equip your trailer with the KEITH ® ® WALKING FLOOR system. We take great pride in manufacturing the simplest, lowest maintenance self- ®...

  • Page 5: Declaration Of Incorporation

    In response to a reasoned request by national authorities, relevant information on the partly complete machinery will be transmitted as hard copies or digital files, unconstrained by intellectual property rights. This partly completed machinery must not be put into service until the final machinery into which it is to be  incorporated has been declared in conformity with the provisions of Directive 2006/42/EC. The person authorized to compile the technical file is:  KEITH WALKING FLOOR Europe Harselaarsweg 113 3771 MA Barneveld The Netherlands _________________________________ R.

  • Page 6: Keith ® Walking Floor ® Unloading System Limited Warranty

    Unloading system must only be used as recommended by KEITH Manufacturing Co. for normal use and service. This means the loading and/or unloading of uniformly distributed, non-corrosive material, properly restrained and secured, on properly maintained public roads, with gross vehicle weights not in excess of factory rated capacity.

  • Page 7: Warranty Registration Card

    Model / Serial Number: ________________________________________________________________ Purchased From: ____________________________________________________________________ Type of Material Loaded/Unloaded: ______________________________________________________ I have fully read the KEITH Manufacturing Co. warranty information and fully understand and agree to the terms of the warranty. Name: ___________________________ Date: __________ Signature: __________________________ DOC06387 Rev.

  • Page 8: Safety

    1.1 General Safety 1.1.1 Intended Function and Expected Use: ® ® 1.1.1.1. The KEITH WALKING FLOOR system is a reciprocating slat conveyor primarily intended to load, hold, or unload bulk materials. It can also handle unit loads such as pallets by using special handling techniques and possibly additional safety controls. The system is supplied as a kit primarily intended for installation into mobile trailers or truck bodies. The floor is often loaded through an open trailer top or through the rear doors. ...

  • Page 9: Personal Protective Equipment

    1.1.6.2. Overheated oil can degrade rapidly. Hot oil and the resulting hot surfaces can cause burns. Do not allow the oil temperature to exceed 140 °F [60 °C]. 1.1.6.3. KEITH recommends some or all of the following temperature control measures depending on the circumstances. High duty cycle systems and hot environments will require more control measures.

  • Page 10: Design / Installation Safety

    Follow all pipe, tubing, fitting, and hose manufacturer installation and routing guidelines. 1.2.5.2. Hydraulic piping should be supported and isolated from vibration. Contact KEITH for recommendations on installation. 1.2.5.3. Place protective shrouds around the hydraulic tubing in any areas that may have operators or people frequently nearby.

  • Page 11: Controls

    1.2.6.5. Do not allow the floor to move material toward the front of the trailer when material is  contacting the front wall. KEITH recommends installing limit switches to prevent this. In the absence of a sensor switch, the operator must be keenly aware of the load position, and the control system must require the operator to hold the run signal in the on position to continue running, such that releasing the run signal causes the floor to stop ...

  • Page 12: Marking Of Machinery

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive 1.3 Marking of Machinery 1.3.1 Safety Decal Placement Guides Safety Decal Placement Guide: KICD, KFD & RUNNING FLOOR II w/Electric Control Valve (Left Side Controls) ®...
  • Page 13 OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive Old - 2019 2020 - Future Description Pressure can build when material is compacted. Doors can open violently causing serious injury or death.  Do not operate floor with doors closed.   Stay clear to open doors. Pinch point can cut or crush causing serious injury.

  • Page 14: Serial Plate

    Madras, OR 97741 USA The Netherlands Container Drive MODEL: ____________________________ SERIAL #: ____________________________ D.O.M.: ____________________________ LOAD CAPACITY: ____________________________ MAX PRESSURE: ____________________________ MAX FLOW: ____________________________ DRIVE WEIGHT: ____________________________ www.KeithWalkingFloor.com WALKING FLOOR and KEITH are registered trademarks of KEITH Manufacturing Co. DOC06387 Rev. C...

  • Page 15: Specifications

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive Specifications 2.1 Hydraulic Drive Unit Drive Style: KICD 108 mm Cylinder Bore Diameter: [4.25 in] 152 mm Cylinder Stroke Length: [6.0 in] Required Relief Valve Min: Min.: 195 bar [2,800 PSI] Pressure Range:...

  • Page 16: General Wet Kit Specifications

    Valve than full open relief pressure ~ 210 bar [3000 PSI]. Contact KEITH in your region for specific recommendations and advice regarding wet kits. * If the information about your pump and pressure relief valve is not known, have a pressure/ flow check done by a professional.

  • Page 17: Floor To Wet Kit Diagram

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive 2.3 Floor to Wet Kit Diagram DOC06387 Rev. C...

  • Page 18: Operation

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive Operation 3.1 How it Works Initial Stage All slats are staged together toward the direction of material travel (discharge end). Stage 1 The first group of slats (approximately every 3rd slat)  moves under the load. Load does not move.

  • Page 19: Oil Flow Diagram

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive 3.2 Oil Flow Diagram UNLOADING CYCLE Blocked Return Oil Pressure Return Standing Oil View from Underneath Looking Up Front Front Check Valves Check Valves Control Valve Restrictor Valve Control Valve...
  • Page 20 OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive LOADING CYCLE Blocked Return Oil Standing Oil Pressure Return View from Underneath Looking Up Front Front Control Valve Control Valve Restrictor Valve Restrictor Valve Open Open Open...

  • Page 21: Component Location Guide

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive 3.3 Component Location Guide Basic KICD Component Locations (Left Side Manual Controls) Drive Frame Rod Bearing Block Pressure (Front of Trailer) Return Cross-Drive Rod Clamps (6) Cross-Drive Actuator Supports (4) Drive Shoes...

  • Page 22: Component Descriptions

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive 3.4 Component Descriptions Component Description A closed valve routes oil to the drive system (floor On). Ball Valve (On/Off) An open valve allows free flow of oil back to the tank (floor Off). Switches the hydraulic pressure from one end of the cylinders to the opposite Switching end of the cylinders, which causes the cylinders to change from the restaging Valve sequence to moving the material then back again.

  • Page 23: Component Identification

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive 3.5 Component Identification Ball Valve (On/Off) (Manual) Switching Control Valve - Manual Valve (Load/Unload) (Left side controls) Cylinder Cross-Drive #2 Cross-Drives #1 & #3 (Shape, size and quantity of shoes on cross-drives may vary by configuration.) DOC06387 Rev. C...

  • Page 24: Start-Up

    3.6 Start-Up 3.6.1 Before Initial Start-Up • Read through this manual. If there is any confusion, contact KEITH to resolve any concerns before operating this system (See 6.0 Contact Information section).  • Ensure that the hydraulic reservoir has the recommended amount of oil, as well as the correct type of oil (see 2.2 the Specifications section of this manual for details about your system).

  • Page 25: Standard Operating Procedures

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive 3.8 Standard Operating Procedures 3.8.1 Manual Controls DANGER: ALWAYS have doors fully open! NEVER, under any circumstances, engage the ® WALKING FLOOR unloader with the doors of the truck/trailer closed. Catastrophic failure to the truck/trailer, as well as serious injury or death may occur.

  • Page 26: Maintenance

    • Inspect cross-drive support bearings, wearpads, tubes and shoes for wear. (See 4.4 Cross- Drive Wear Component Diagram section). Replace as needed. Inspect floor wear bearings and seals for excessive wear (especially above the tires). (See 4.5  • Floorings Wear Component Diagrams section) Replace as needed. Inspect floor slats for wear. If discharge end of slats are worn down more than 75% of original  • material thickness, rotate all floor slats end for end, to increase life of the floor. If floor has  already been rotated, contact KEITH for replacement slats. DOC06387 Rev. C...

  • Page 27: Bolt Torque Requirements

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive 4.3 Bolt Torque Requirements Description Size Quantity Torque Values Tube Clamp Bolts M6 CL8.8 HCS Varies Snug * Cylinder Pack Bolts 150 ft.-lbs M16 CL10.9 HCS (Requires blue Loctite [205 N·m] 61 N·m...

  • Page 28: Cross-Drive Wear Component Diagram

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive 4.4 Cross-Drive Wear Component Diagram Nut Bars are inside shoes Shoes are on top of Tubes (Qty varies) Cross-Drive Tubes (3) Wearpads are on top of Cross-Drive Support Members (4) Cross-Drive Support Members (4)

  • Page 29: Flooring Wear Component Diagrams

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive 4.5 Flooring Wear Component Diagrams Floor Wear Bearings & Seals * Deck Floor Slats Seal Standard 4608302 Bearing Hold Down Bearing T-Block Seal Splash Guard Hold Down Seal Cross-Sectional View...

  • Page 30: Troubleshooting

    KICD - Container Drive KICD - Container Drive Troubleshooting 5.1 Check List Before contacting KEITH for technical assistance, please verify the following: 9 Wet Kit:  Does your entire wet kit system meet the requirements in  2.2 Specifications section in  this manual?  (Additional Wet Kit information is available on our website.) 9 Plumbing: Is your entire system plumbed per the 2.3 Floor to Wet Kit Connection Diagram in Specifications section in this manual?

  • Page 31: Problem / Solution - Troubleshooting

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive 5.2 Problem / Solution - Troubleshooting The cycle begins, then the floor stops. Problem: The first cross-drive (#1) moves forward to the front of the vehicle, second  Specific Problem: cross-drive (#2) moves forward, the third cross-drive (#3) moves forward, then  the system stops. Possible Cause: The switching valve is not switching correctly. The threaded rod nuts on the discharge end of the threaded actuator rod are Solution: not adjusted correctly.
  • Page 32 OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive Specific Problem: All cylinders extend together toward the front of the vehicle. Possible Cause #1: The load/unload cartridge valve has malfunctioned. Solution: Replace the load/unload cartridge valve. Possible Cause #2: The check valves at the front end of cylinders #1 and #2 have malfunctioned.

  • Page 33: Adjustments & Replacements

    KICD - Container Drive 5.3 Adjustments & Replacements 5.3.1 Switching Valve Adjustment Available Videos:     KEITH Website: https://www.keithwalkingfloor.com/support/troubleshooting/ YouTube.com: https://www.youtube.com/watch?v=F2kJT_VdAqo Required Tools:   (2)   17 mm open-end wrenches. NOTE: Many switching valves are unnecessarily replaced when they are only in need of adjustment. Always adjust the switching valve as described below.
  • Page 34 OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive Switching Valve Adjustment Diagram 1. Switching Valve Assembly 4. M10 Flat Washers 2. M10 Threaded Rod 5. Grommet 3. Actuator Tab 6. M10 Jam Nuts Detail B Detail A DOC06387...

  • Page 35: Check Valve Replacement

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive 5.3.2 Check Valve Replacement Required Tools:      (1)  32 mm [1-1/4”] x 12.5 mm [1/2”] Drive socket      (1)  12.5 mm [1/2”] Drive ratchet      (1)  Small Magnet      (1)  Flashlight      (1)  Bucket and shop towels Check Valve Disassembly: 1. Run the cylinder away from the check valve to free it. 2.

  • Page 36: Control Valve & Restrictor Valve Replacement

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive 5.3.3 Control Valve & Restrictor Valve Replacement O-Ring Plunger Back-up Required Tools:      (1)  32 mm [1-1/4”] x 12.5 mm [1/2”] Poppet Drive socket      (1)  12.5 mm [1/2”] Drive ratchet      (1)  13 mm [9/16”] hex bit      (1)  Small Magnet Control Valve Valve Restrictor      (1) ...
  • Page 37 OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive DOC06387 Rev. C...
  • Page 38 OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive Cylinder Pack Installation Step #1 If all three cross-drives were fully retracted to the rear, unload end of the trailer before removing the old cylinder pack, then the threaded rod pads should be in the correct positions for installation.
  • Page 39 OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive DOC06387 Rev. C...

  • Page 40: Technical Support

    OWNER / OPERATOR MANUAL OWNER / OPERATOR MANUAL KICD - Container Drive KICD - Container Drive 5.4 Technical Support Please have the following information readily available before contacting KEITH for support: Model Number (Located on the Serial Plate of the drive unit) (See 3.3 Component Location Diagram) • Serial Number (Located on the Serial Plate on the drive unit) (See 3.3 Component Location Diagram) • Number of floor slats • • Vehicle make and unit installer KEITH Technical Support Contact Information: Website: www.KeithWalkingFloor.com...
