- Page 1 l i nd a b | w e si m p l i fy c onst r u ct i on LindabLinAir Heat Pump Ventilator...
-
Page 2: Table Of Contents
LinAir HPV Content Safety considerations ................................Safety labels .................................... . Cautions ....................................Product dimensions ..................................Product specifications ................................... Control system wiring diagrams ..............................Control system wiring diagrams ..............................Installation location ..................................Before installation ..................................Installation cautions ..................................Installation clearance ..................................Drainpipe installation .................................. -
Page 3: Safety Considerations
• Do not place anything on the machine as this can be good electrical insulation. dangerous. • Complete the grounding engineering according to the Electrical Safety Regulations to avoid leakage. Lindab reserves the right to make changes without prior notice 2021-08-07 W00-20-14... -
Page 4: Product Dimensions
LinAir HPV Product Dimensions Figure 1. Product dimensions for LinAir 400 Heat Pump Ventilator Figure 2. Product dimensions for LinAir 500 and 700 Heat Pump Ventilators... -
Page 5: Product Specifications
1040 x 820 x 1440 134/170 92/120 134/170 Net/ Gross weight R410A/0.78kg Refrigerant R410A/0.48kg R410A/0.78kg Table 1. Product specification for LinAir 400, 500 and 700 Airflow Curves Temperature Effiency Temperature Effiency Effiency (%) Effiency (%) Temperature Effiency Effiency (%) Airflow（m3/h）... -
Page 6: Control System Wiring Diagrams
LinAir HPV Control System Wiring Diagrams Figure 3. Wiring diagram for LinAir 400 Heat Pump Ventilator... -
Page 7: Control System Wiring Diagrams
| w e si m pli f y co nst ru ct io n Heat Pump Ventilator Figure 4. Product dimensions for LinAir 500 and 700 Heat Pump Ventilators Lindab reserves the right to make changes without prior notice 2021-08-07 W00-20-14... -
Page 8: Installation Location
• If the machine is installed on a metal base of the construction, the electrical insulation must be done strictly according to the technical standards of electrical equipment. Compressor 80mm clearance 50mm clearance Front of the ventilator (white) LinAir 400- 300mm clearance LinAir 500/700- 350mm clearance Figure 5. Installation clearance... -
Page 9: Drainpipe Installation
15 meters. Modbus connector P+ and N- should only be applied when the project requires central control. Drainpipe connector Figure 6. Drainpipe connection PCB Inside ventilator Controller and sensors box Figure 7. Electrical wiring Lindab reserves the right to make changes without prior notice 2021-08-07 W00-20-14... -
Page 10: Power Cord Requirement
1. If any abnormality is found (like a scorching smell), shut down the power, and contact Lindab, if use is continued the machine may be damaged and cause electric shock or fire, maintenance can only be conducted by a professional. -
Page 11: Controller Home Page
Ventilation mode - to set the fan speed, then to confirm. Auto mode - to set cooling and heating temperature, then to confirm. Figure 9. Mode switch and mode settings Lindab reserves the right to make changes without prior notice 2021-08-07 W00-20-14... -
Page 12: Controller Settings Menu
LinAir HPV Setting Button Press setting button to enter basic setting, advanced A) Press basic setting to enter the basic setting page. setting, data query or maintenance setting. Press PM2.5 or CO value to set the targeted value, these values will influence the SA fan and EA fan speed after setting temperature achieved (compressor off). -
Page 13: Controller Filter Life Settings
ADVANCED SETTINGS ARE ONLY FOR ADMINISTRATORS, INCORRECT SETTINGS MAY PREVENT THE VENTILATOR FROM WORKING. Figure 15. Advanced settings Figure 16. Filter alarms Lindab reserves the right to make changes without prior notice 2021-08-07 W00-20-14... -
Page 14: Controller Correction Value And Return Difference Settings
5555, if the ventilator works OPTIONS, ONLY PROFESSIONALS SHOULD VISIT fine, there is no need to visit this page. THIS PAGE, INCORRECT SETTINGS WILL RUIN THE VENTILATOR SYSTEM, PLEASE CONTACT LINDAB FOR THE PASSWORD IF NECESSARY. Figure 19. Data queries Figure 20. Maintenance settings... - Page 15 That means less carbon emissions in nature and less energy wasted. We simplify construction www.lindab.co.uk Lindab reserves the right to make changes without prior notice 2021-08-07 W00-20-14...
