- Page 1 li nda b | we sim pl i fy c onst ru ction Atrium Plana Service & maintenance...
-
Page 2: Installation
1.0 Installation 1.1 Product description Lindab’s heating and cooling panel Atrium Plana can be mounted almost anywhere in the ceiling or on the wall and primarily provide heating/cooling by radiation. The radiation share for the panels exceeds 50% to 60%, compared to approx. 5% for conventional finned products. - Page 3 l in d a b | w e s i m p l i f y c on s t r u c t io n Service & maintenance Atrium Plana 1.4.1 Push-on fittings – Please ensure that all pipes and fittings are undamaged, as even small dents and scratches potentially pose a risk of leakage in the system.
- Page 4 li nd ab | w e s im pli fy c on st r u ct i o n Service & maintenance Atrium Plana Push-on valve Notice! The connection pipes are internally soft-welded why it’s not allowed to solder the panel to the pipes. 1.4.2 Compression fitting –...
- Page 5 l in d a b | w e s i m p l i f y c on s t r u c t io n Service & maintenance Atrium Plana – The copper insert should be placed inside the pipe on the panel. Always support the copper pipe coil when inserting the copper insert into position.
- Page 6 li nd ab | w e s im pli fy c on st r u ct i o n Service & maintenance Atrium Plana After removing the protection cover, make sure that the pipe is intact and undam- aged, especially at the pipe end. Crocked or in other ways imperfect pipe ends will result in leaks.
- Page 7 l in d a b | w e s i m p l i f y c on s t r u c t io n Service & maintenance Atrium Plana 2.0 Commissioning 2.1 Product labeling Label location exterior (On insulation, above water connection) Label location interior (Under insulation, above water connection).
-
Page 8: Maintenance
Select “Atrium Plana ” • Select “Environmental declaration” 4.3 Working and test pressure – Lindab’s waterborne products have been manufactured and tested according to the Pressure Equipment Directive 97/237EC. The products are classified as SEP – Sound Engineering Practice. – Pressure table... - Page 9 l in d a b | w e s i m p l i f y c on s t r u c t io n Service & maintenance Atrium Plana 4.4 Water quality – The water preparation and maintenance for the panel water circuit should be handled by a specialist.
- Page 10 Änderungen vorbehalten. IT - Qui potete trovare istruzioni di montaggio, informa- zioni sul prodotto ed un supporto tecnico qualificato Tel. 011 9952099 - e-mail: lindab@lindab.it www.lindab.it Soggetto a modifica senza obbligo di preavviso. FR - Vous trouverez les fiches produits ou de montage actualisées ainsi que les coordonnées du support télépho-...
