GE Profile PHP900SMSS Dimensions And Installation Information

PHP900SM
GE Profile 30" Electric Induction Cooktop
™
Dimensions and Installation Information (in inches)
Note: Check local codes for required breaker size
†
KW Rating
Important: Allow 12" minimum vertical
240V
7.7
clearance between the cooktop bottom and any
208V
5.8 combustible surfaces. Free area not required
when installing wall oven underneath cooktop.
Breaker Size
Refer to installation instructions. Requires a
240V
40 Amps
15" minimum from cooktop to adjacent
†
overhead cabinets. Units are furnished with
208V 40 Amps
†
a 36" flexible armored cable.
Note: 36" Ribbon cooktops are approved for use over GE 30" Single Wall
Ovens and Warming Drawers only. Refer to cooktop and wall oven/
warming drawer installation instructions packed with product for current
dimensional data. If installed with a GE Profile
consult both the cooktop and downdraft installation instructions packed with
product before installing. Cooktop gas/electric supply may need to be
re-routed to install downdraft. The countertop must be at least 26" deep
with a flat surface area of 23-1/2" or more, front to back. In addition,
other clearances to the front edge of the countertop must be considered,
especially on raised bullnose countertops. Consult cabinet and countertop
manufacturer's specs for flush mount installation prior to install.
Installation Information: Before installing, consult installation instructions
packed with product for current dimensional data.
For answers to your Monogram, ®
GE appliance questions, visit our website at
®
ge.com or call GE Answer Center
800.626.2000.
Telescopic Downdraft System,
™
GE Profile ™ or
service,
®
21-3/8
29-3/4
Cooktop
19-5/8
28-1/2
2-1/2**
Required
* Depth of unit at conduit connection location (rear) is
6-1/4" on models PP980/975/950/945 and 4-5/8"
on models PHP960/900, PP972/962/942/932/912
and JP6SS/356/346/340.
**Raised bull nose countertops may require up to
3/8" additional clearance to prevent interference
with curved front.
Above illustration intended for dimensional reference only.
Refer to photograph for actual product appearance.
13" MAX.
depth
3-1/4*
30" MIN. to
unprotected
cabinet
15" MIN.
to cabinet
1-3/4" to
rear wall
2" MIN.
clearance to
side wall
from cut-out
Electrical junction box 16" MIN.
below countertop
Specification Revised 2/10
2" MIN.
clearance to
side wall
from cut-out
Cut should
not interfere
with cabinet
structure
at front
