MiFleet + Vision Quick Start Manual

Additional documentation and support is available at:
https://mifleet.us/support | support@mifleet.us | 866.MiFleet Option 2
MiFleet + Vision Quick Start Guide
Full HD Duel Camera - Dash Cam Solution
1. Remove all contents from box.
2. Verify parts list inventory (Fig. 1).
Part Image
Forward Exterior Facing Camera
Driver Interior Facing Camera
External GPS Module
10 PIN Power Cable
Star Torque Wrench
4G Antennas
(only with 4G device)
Carrier SIM Card
3. Open side panel of exterior facing camera using
star torque wrench.
4. Verify SIM & SD card are inserted correctly.
Fig. 2
5. Verify all connections are tight and correct based on
figure 3 & 4 below.
4G LTE + WiFi Device
Fig. 3
Description
SD Card
SIM card slot,
insert face down.
SD card slot,
insert face down.
WiFi Only Device
Fig. 4
PLEASE NOTE:
professional installer preform these steps to insure accuracy
Fig. 1
with device installation and furthermore to ensure vehicle
Total
Parts health upon completion of installation. MiFleet or it's
affiliates are NOT RESPONSIBLE for any damage to any
1
vehicle with installed equipment.
1
1. Clean windshield - DO NOT SKIP STEP
2. Mount both cameras temporarily by pealing off 3M
sticky tape on the back and applying camera gently
2
to windshield in specified locations.
3. Neatly tuck hard wiring cables under roof liner on
1
interior vehicle roof fabric over to driver side door
(Green Line Fig. 5)
1
4. Bring cables down through back side of dashboard
paneling down to reach vehicle fuse box
1
5. Connect device power to proper fuse connections;
black to ground, red to 12V power, and yellow to ACC
1
12V ignition.
6. Choose either left or right side of windshield to mount
1
antennas. Peal the 3M sticky tape off the back side and
firmly stick antennas to windshield.
7. Tuck antenna cords under interior lining on roof just
like in step 3
8. Mount GPS module to dashboard by pealing off the
3M sticky tape and press firmly.
9. Bring cables up right side of vehicle and tuck behind
interior lining
10. Device is now installed into vehicle, please continue
to camera configuration on reverse side.
Interior Camera
Fig. 5
1

QUICK DEVICE INSTALL - START HERE

We highly suggest that you have a
.
.
(Yellow Line Fig. 5)
.
(Pink Line Fig. 5)
Antenna Locations
Exterior Camera
Note: tuck camera behind rear
view mirror for easy visibility.
.
(Blue Line Fig. 5)
Rear View Mirror
GPS Module
Continued...
