- Page 1 MiFleet Dash Cam Hardware Install Guide For more information, please visit our website www.MiFleet.us/support...
-
Page 2: Items Included In The Box
Power input cable with PB 1 pcs Cable alarm input LENS CLEANING 2 Lens Wipes To clean your camera lenses 2 pcs W I P E Wrench Used to open or close SIM door 1 pcs For more information, please visit our website www.MiFleet.us/support... - Page 3 Marker Used for Front facing installation 1 pcs For shearing and stripping cables Wire Strippers 1 pcs (for vehicles without OBDII port) Used for dressing exposed wire Electrical Tape 1 pcs ends For more information, please visit our website www.MiFleet.us/support...
- Page 4 DRIVER FACING CAMERA (Internal Facing) Fig. 1 FRONT FACING CAMERA (Road Facing) GPS ANTENNA NOT USED NOT USED IGNITION ON - Yellow Wire GROUND - Black Wire POWER IN CONSTANT 12V - Red Wire For more information, please visit our website www.MiFleet.us/support...
- Page 5 DRIVER FACING CAMERA (Internal Facing) Fig. 1 FRONT FACING CAMERA (Road Facing) GPS ANTENNA NOT USED NOT USED IGNITION ON - Yellow Wire GROUND - Black Wire POWER IN CONSTANT 12V - Red Wire For more information, please visit our website www.MiFleet.us/support...
- Page 6 Img. 4 Wire Locations Img. 5 Img. 6 6. Zip tie (if available) camera cables to existing vehicle cables already hidden under paneling to ensure a proper and long lasting install. Once complete, reinstall panel. For more information, please visit our website www.MiFleet.us/support...
- Page 7 10. Adjust camera angle by loosing screw and rotating camera lens up and down. Once in desired location, tighten screw to hold position shown in images 7 & 8. Img. 8 Img. 7 For more information, please visit our website www.MiFleet.us/support...
- Page 8 Remove side panel, zip tie antenna cable to existing cables, and replace side panel. 15. Remove 3M backing and firmly stick GPS antenna to dashboard as shown in image 10. Img. 11 Img. 12 Img. 13 For more information, please visit our website www.MiFleet.us/support...
-
Page 9: Basic Troubleshooting Steps
Basic Troubleshooting Steps LED indicator There is only one LED status indicator on the MiFleet + Vision base. The working status of device can be reflected by the lighting. • No light on device means the device is not powered on.
