U-Line H-4078 Installation Manual

H-4078
PLASTIC RACK
PROTECTOR
INSTALLING PLASTIC RACK PROTECTOR
1. Position plastic rack protector behind the back corner
of the rack leg so the tab latches onto the rack leg.
Stretch rack protector around rack leg. (See Figure 1)
2. Press center of rack protector down, pushing tab over
opposite corner of rack leg. (See Figure 2)
PAGE 1 OF 3
1-800-295-5510
uline.com
INSTALLATION
Figure 1
RACK
LEG
Tab
Figure 2
RACK
LEG
Tab
3. Rotate rack protector around rack leg. Snap tab
securely over back corner and secure with bolt and
wing nut. (See Figure 3)
4. Stack to desired height. (See Figure 4)
Para Español, vea página 2.
Pour le français, consulter la page 3.
Figure 3
RACK
Figure 4
0621 IH-4078
