FOXEER Reaper Nano VTX Manual

Advertisement

Quick Links

Reaper Nano
VTX
特点:
1. 滤波纯净,抗干扰性能优异,全油门画面依然
稳定。
2. 杂散小。
3. 不飘频。
4. 尺寸小,功率高。
5. 超低功耗。
规格:
1. 尺寸: 12×16mm
2. 连接口: UFL
3. 显示灯: 3颗LED
4. 重量: <1g
5. 功率: 25/100/200/350mW
6. 输入: 5V
7. 输出: 5V
8. 通道: 40CH
9. 遥控器协议: Tramp
1.LED灯说明
LED
说明
红灯
功率
绿灯
频段
蓝灯
通道
2.按键操作方法
长按3秒,进入频段设置,短按设置不同频段;
再长按3秒,进入通道设置,短按设置不同通道;
继续长按3秒,进入功率设置,短按设置不同功率。
3.频率表
Band
CH1
CH2
CH3
CH4
CH5
Band A
5865
5845
5825
5805
5785
Band B
5733
5752
5771
5790
5809
Band E
5705
5685
5665
5645
5885
5740
5760
5780
5800
5820
Band F
Band R
5658
5695
5732
5769
5806
CH6
CH7
CH8
5765
5745
5725
5828
5847
5866
5905
5925
5945
5840
5860
5880
5843
5880
5917
