- Page 1 3950 NW 120 Ave, Coral Springs, FL 33065 TEL 561-955-9770 FAX 561-955-9760 Ford A²B to 12-channel Analog & Digital sound processor NTV-KIT873...
- Page 2 04/30/18 WARNING: Do not connect any RCA cables to the ZEN-A2B interface or NTV-DOC320 additional processors prior to properly grounding aftermarket amplifier(s)! Overview The ZEN-A2B processor seamlessly converts 2018+ Ford factory A²B (Automotive Audio Bus) to 12-channel analog RCA and TOSLink output. Adding aftermarket amplifiers to the OE B&O or Revel amplified SYNC3 system has never been so simple and seamless.
- Page 3 04/30/18 NTV-DOC320 ZEN-A2B Installation 1. For ZEN A²B installations, the factory amplifier must be removed and the ZEN-A2B can be installed into its place. If this vehicle is not amplified from factory then this interface is not needed. 2. After locating the factory amplifier, disconnect it entirely as it will no longer be in use. Connect the white, 10-pin plug removed from the amp (houses the A²B wires) and connect to the ZEN A2B connector labeled ‘A²B’.
- Page 4 04/30/18 NTV-DOC320 ZEN-A2B General Installation Notes • Tuning tips: 1. Before beginning tuning process (especially with external EQ/Processors), set Bass & Treble on the head unit for each source to flat (0). 2. Begin with amplifier/EQ gains all the way down. 3.
- Page 5 04/30/18 NTV-DOC320 ZEN-A2B System Layout (analog) For ZEN-A2B installations, the factory amplifier MUST be removed. P a g e...
- Page 6 04/30/18 NTV-DOC320 ZEN-A2B System Layout (digital TOSLink) For ZEN-A2B installations, the factory amplifier MUST be removed. P a g e...
- Page 7 04/30/18 NTV-DOC320 ZEN-A2B Technical Specifications Hardware & Software Current HW version: --1r0-- Current SW version: ZEN-A2B-xxxx Compatible SW (update) OS: Windows 7 (64 bit), 8, 10 INPUT Digital Input AB Fiber Optic OUTPUT Digital Outputs: TOSLink Digital Outputs supported: 24bit/48kHz Frequency Response (digital): 18Hz –...
- Page 8 04/30/18 NTV-DOC320 P a g e...
