Install Toolchain for Firmware Development ........................5 Import and Compile an Example Project from CMSIS Pack ....................6 Flash and/or Debug the Example ............................6 Verify Data Collection Firmware ............................8 Verify Knowledge Pack Firmware ............................. 9 APPENDIX ..................................10 Enclosure for RSL10-SENSE-GEVK ..........................10 http://onsemi.com...
Analytics Studio can be found on This user guide describes firmware toolchain installation and verification of onsemi.SensiML CMSIS pack. The CMSIS pack contains example project for data collection and knowledge pack generation using RSL10 sense board (RSL10-SENSE-GEVK). Detailed description about RSL10 Evaluation board and RSL10 Sense board can be found in following links:...
Page 4
RSL10-SIP-001GEVB to flash RSL10-SENSE-GEVK. Connect ribbon cable from 10-pin JTAG connector P2 (RSL10-SIP-001GEVB) to 10-pin connector on RSL10-SENSE-GEVK. Connect USB cable to the computer and follow instructions for flashing the board. Figure 3. Flashing RSL10 sense board using RSL10 Evaluation board http://onsemi.com...
Pack” as per step 3. 6. Download and install following packs from Technical Documents section as per step 3. “ ” Bluetooth IoT Development Kit CMSIS Pack “onsemi.RSL10SensiML Pack” 7. Download and install latest version of “J-Link Software and Documentation pack”.
2. Right-click on the project name in Project Explorer and select “Build Configurations” to “Release” or “Debug”. Next, select “Build Project” to compile the project. Figure 8. Set Build Configuration for a Project Flash and/or Debug the Example 1. Create Run/Debug configuration for the project. Select “Run” -> “Run Configurations…”. Figure 9. Open Run Configurations http://onsemi.com...
Page 7
4. To flash the board, click green play button looking icon in “Run” mode. Figure 12. Run the configuration to Flash 5. To debug, click green bug looking icon in “Debug” mode. Figure 13. Start Debug configuration 6. Detailed instructions about using the IDE can be found in RSL10 Getting Started Guide. http://onsemi.com...
9. If both the boards have correct firmware and are connected with each other over Bluetooth, serial terminal should print sensor JSON configuration every 1 second. Figure 14. Sensor JSON Configuration from Data Collection Firmware 10. The boards are now ready to connect with Data Capture Lab for data collection. http://onsemi.com...
JSON formatted model and classification messages. Figure 15. JSON Formatted Model and Classification messages from Knowledge pack Firmware 11. Knowledge pack firmware can be tested with Open Gateway software provided by SensiML for easier readability of model and classification detection. http://onsemi.com...
Getting Started Guide for Edge AI Processing using RSL10 Sensor kit Appendix Enclosure for RSL10-SENSE-GEVK 3D printable enclosure files for RSL10 sense board can be found in onsemi.SensiML CMSIS pack. Figure 16. 3D model for RSL10 Sense board Enclosure http://onsemi.com...
Page 11
LIMITATIONS OF LIABILITY: onsemi shall not be liable for any special, consequential, incidental, indirect or punitive damages, including, but not limited to t he costs of requalification, delay, loss of profits or goodwill, arising out of or in connection with the board, even if onsemi is advised of the possibility of such damages. In no event shall onsemi’s aggregate liability from any obligation arising out of or in connection with the board, under any theory of liability, exceed the purchase price paid for the board, if any.
