RSL10 Stand-Alone Flash Loader Manual
M-20823-009
June 2023
©
SCILLC, 2023
Previous Edition © 2021
"All Rights Reserved"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RSL10 and is the answer not in the manual?

Questions and answers

Related Manuals for onsemi RSL10

Summary of Contents for onsemi RSL10

  • Page 1 RSL10 Stand-Alone Flash Loader Manual M-20823-009 June 2023 © SCILLC, 2023 Previous Edition © 2021 “All Rights Reserved”...

  • Page 2: Table Of Contents

    RSL10 Stand-Alone Flash Loader Manual Table of Contents Page 1. Introduction ....... .

  • Page 3: Introduction

    This manual provides the information that you need to use the stand-alone flash loader. It describes the operations that the flash loader can perform, and explains how to configure the flash loader to connect to an RSL10 radio IC. The stand-alone flash loader is used to program, erase and read flash memory in RSL10.

  • Page 4: Flash Loader Overview

    Figure 1. How the Stand-Alone Flash Loader Communicates with the Radio IC The RSL10 radio IC contains multiple sections, all of which can be managed by the stand-alone flash loader. See the RSL10 Hardware Reference Manual for more information about the sections.
  • Page 5 The stand-alone flash loader has several global options: These options control how the stand-alone flash loader communicates with the RSL10 radio IC. Device options See Section 2.3, “Supported Flash Loader Hardware” for information on these options.

  • Page 6: 2.2.1 Flash Regions

    RSL10 Stand-Alone Flash Loader Manual 2.2.1 Flash Regions When the flash loader is performing operations on user-specified regions of flash memory, a standard format is used to specify one or more ranges of addresses in flash memory. start-end,start-end,...,start-end Each address is a decimal or C-formatted hexadecimal address.
  • Page 7 RSL10 Stand-Alone Flash Loader Manual Table 2. Common Errors and Their Solutions Description of Error Possible Causes Possible Solutions No emulators connected to the USB You have not connected the J-Link Connect the J-link emulator, make sure window. Asks for IP address.

  • Page 8: Flash Loader User Interface

    The Tools page allows you to erase and read the contents of flash memory. • The Options page allows you to control how the flash loader accesses the RSL10 radio IC. For a list of all the tasks you can do with this application, and where to find the corresponding graphical user interface or command line interface steps, see Table 1 on page 5.

  • Page 9: The Options Page

    3.3 T PTIONS Use the controls on the Options page (Figure 4) to control how the flash loader accesses the RSL10 radio IC. Figure 4. The Stand-Alone Flash Loader Options Page In the Device section of the page, you can select either a USB or Network J-Link device: •...

  • Page 10: The Progress Dialog

    The stand-alone flash loader displays the progress dialog box shown in Figure 5 when performing any operation that communicates with the RSL10 radio IC. The dialog shows the current operation at the top, the overall progress in a progress bar, and various progress and status messages in the large text box.

  • Page 11: Command-Line Usage

    To start the stand-alone flash loader from the command line, navigate to the location of the Flashloader.exe file in the RSL10 Utility Apps folder. Add the location of Flashloader.exe to the system PATH environment variable to allow easy access to this command.

  • Page 12: The Program Command

    RSL10 Stand-Alone Flash Loader Manual 4.1 T ROGRAM OMMAND Use the command to write the contents of a data file to flash memory. By default, the flashloader program command only erases the regions of flash memory that are being written. The...

  • Page 13: The Verify Command

    RSL10 Stand-Alone Flash Loader Manual 4.3 T ERIFY OMMAND Use the command to perform two similar operations: flashloader verify Verify that a region of flash memory is erased. Verify that the contents of flash memory match the contents of a data file.
  • Page 14 All operating parameters, including “Typicals” must be validated for each customer application by customer’s technical experts. onsemi does not convey any license under its patent rights nor the rights of others. onsemi products are not designed, intended, or authorized for use as a critical component in life support systems or any FDA Class 3 medical devices or medical devices with a same or similar classification in a foreign jurisdiction or any devices intended for implantation in the human body.
