49-2040-004
Date 05/07
INSTALLATION INSTRUCTIONS
SP200 SHOWER PANEL
Jason InternatIonal, Inc.
8328 MacArthur Drive • North Little Rock, AR 728 • www.jasoninternational.com
50-77-4477 • Fax: 50-77-2333 • Cust. Svc.: 800-255-5766
Page  of 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP200 and is the answer not in the manual?

Questions and answers

Related Manuals for JASON Hydrotherapy SP200

Summary of Contents for JASON Hydrotherapy SP200

  • Page 1 49-2040-004 Date 05/07 INSTALLATION INSTRUCTIONS SP200 SHOWER PANEL Jason InternatIonal, Inc. 8328 MacArthur Drive • North Little Rock, AR 728 • www.jasoninternational.com 50-77-4477 • Fax: 50-77-2333 • Cust. Svc.: 800-255-5766 Page  of 5...
  • Page 2 Figure 1 - Dimensions Page 2 of 5...

  • Page 3: Technical Data

    Technical Data Operating Pressure: max. 45 psi Recommended pressure: 30.60 psi Test pressure: 232 psi Max. hot water temperature: 76°F * Recommended hot water temperature: 20°F - 40°F Flow rate @ 45 psi Handshower 2.5 gpm Bodysprays < gpm each Protection against back siphonage is provided by check valves in the hot and cold supply elbows.

  • Page 4: Preparation For Installation

    Preparation for Installation . Install /2” IPS nipples for the hot and cold water sup- plies at the locations shown on the diagram. The nipples should extend 5/8” outside the surface of the finish wall. 2. For proper operation of the unit, the hot supply should be on the left, and the cold supply should be on the right.

  • Page 5: Installation Instructions

    Installation Instructions 1. Wrap the nipples with several layers of Teflon tape. 2. Install the elbows included with the panel. The outlets should point downwards. The elbow should extend no more than 1 1/4” from the surface of the finished wall. Figure 4 See Figure 4 and Figure 5.
  • Page 6 INSTALLATION INSTRUCTIONS (cont.) 8. Hold the panel against the wall. 9. Install the gray plastic insert. (See Figure 8.) 0. Insert the top screw through the front of the panel, the washer and the insert. Screw it into the anchor. (See Figure 8.) Figure 8 .
  • Page 7 INSTALLATION INSTRUCTIONS (cont.) 4. Turn the water on at the main. Push the diverter stem up to turn the water on to the panel. (See Figure 13.) 5. Check all connections for leaks. Figure 13 6. Once you ensure that the connections are watertight, push the diverter stem down to turn the water off to the panel.
  • Page 8 INSTALLATION INSTRUCTIONS (cont.) 20. Make sure that the indexing mark on the thermostatic mixer sleeve is at the 2:00 position. (See Figure 18.) 2. Install the thermostatic mixer handle.(See Figure 18.) 22.Tighten the handle screw with a flat-bladed screwdriver. Figure 18 23.
  • Page 9 Adjust the Slider You can make the slider easier or harder to move. Use a 2.5 mm Allen wrench to turn the set screw clockwise to increase the tension, counter-clockwise to decrease the tension. Figure 21 Justify the Thermostatic Mixer Handle .
  • Page 10 Set the High Temperature Limit Stop (Optional) . Remove the thermostatic mixer handle. 2. Remove the clip and the stop ring from the stem of the thermostatic mixer. (See Figure 25.) Figure 25 3. Turn the water on to the handshower. 4.
  • Page 11 User Instructions Using the Thermostatic Mixer . Turn the handle clockwise to make the water cooler. 2. Turn the handle counter-clockwise to make the water warmer. When the safety stop override is at the 2:00 position, the output water is 00 F, the handle will stop.
  • Page 12 Using the Diverter Pull the lever upward to turn the water on. Pivot the handle to the desired function. There are five functions: . Alll-around shower (handshower and 4 lower bodysprays). Figure 35 (See Figure 35.) 2. Four (4) lower bodysprays. (See Figure 36.) Figure 36 3.

  • Page 13: Scale Removal

    Scale Removal The spray channels are protected by the Rubit self-clean- ing system. Follow these steps to remove scale deposits: . If scale deposits are noticed in the spray channels, turn the water on lightly and rub the spray channels with a finger or a sponge.

  • Page 14: Cleaning Recommendations

    Cleaning Recommendations Modern faucetry and shower products utilize a combination Cleaning Procedures of materials to comply with the needs of the market with • Clean your faucets and shower products as and when regard to design and functionality. required. Regular cleaning will prevent scale buildup and water spotting.

  • Page 15: Replacement Parts

    Replacement Parts Figure 44  handshower 2859XXX 2 slider 97024XXX 3 handshower hose, 63” 28276XXX 4 upper cover 97324000 5 escutcheon 97326000 6 body shower 28406000 7 diverter handle 0490XXX 8 thermostatic mixer handle 3839XXX 9 flange 97858XXX 0 front cover 97859000  sleeve 95032XXX 2 adapter for handle 9708000 3 thermostat cartridge 94282000...
