"TO BE REMOVED FOR USE BY THE OCCUPANT."
Jason International, Inc.
8328 MacArthur Drive
North Little Rock, AR 72118-2029
www.jasoninternational.com
forma
and Designer Microsilk
®
InsTallaTIOn, OPeraTIOn, anD MaInTenanCe
If the carton shows sign of damage, inspect
the product before accepting and describe the
problem on the Bill of lading.
InsPeCTIOn
Inspect the unit prior to installation. In the event of a
problem, DO NOT install the unit.
All components are factory assembled to the bath and the
unit is water tested and inspected prior to leaving Jason
International, Inc.
If the carton shows sign of damage, inspect the product
before accepting and describe the problem on the
Bill of Lading.
NOTe: Transportation and insurance from Jason's
factory are the buyer's responsibility.
Damage sustained in transit is the responsibility of
the carrier. If damage is discovered, the carrier must
be immediately notified in writing with a request for a
representative to inspect the unit. Failure of the carrier
to respond should be reported to the seller and carrier.
Always file a freight claim promptly.
The installer is responsible for ensuring that the unit is
free from defects or shipping damage. In the event of a
problem, DO NOT install the unit.
Jason International is not responsible for damage that
might have been avoided by inspection or testing prior to
installation.
Owner's reCOrD
Dealer:
Date Purchased:
Date Installed:
Installer:
Jason International, Inc. • 501.771.4477
Owner's Manual
®
Damage to the unit during installation will not be covered
by warranty and is the responsibility of the installer.
ALL WARRANTY CLAIMS ON ACRYLIC SURFACe
DAMAGe MUST Be MADe PRIOR TO INSTALLATION.
Inspect plumbing and bath surface for missing or damaged
components. Alert your dealer of any discrepancies.
To protect the unit from damage, keep the bath in the
carton until ready for installation.
eQuIPMenT aCCess
In accordance with Building Codes, service access to
all hydrotherapy bath equipment, controls and electrical
connections must be provided during installation
(Recommended minimum 28" x 17" [71 x 43 cm]).
Insufficient access will hinder repair and maintenance.
Warranty service will not cover costs of providing
equipment access.
Jason offers an optional removable lateral skirt for all
rectangular baths. The skirts are available in matching
acrylic colors and provide convenient access to bath
equipment, as well as an excellent finished appearance.
The Specification Sheet for this bath contains additional
technical information. This sheet can be provided by your
dealer or accessed online at www.jasoninternational.com.
Page 1 of 17
-airMasseur
®
PlaCe serIal nuMBer CarD wITh
PrODuCT COnfIguraTIOn In ThIs BOx
Customer Service : 800.255.5766
Copyright © 2013 Jason International.
49-1010-800
Date 02/13
Baths

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Forma MicroSilk-AirMasseur and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for JASON Hydrotherapy Forma MicroSilk-AirMasseur

  • Page 1 “TO BE REMOVED FOR USE BY THE OCCUPANT.” Jason International, Inc. 49-1010-800 8328 MacArthur Drive Date 02/13 North Little Rock, AR 72118-2029 www.jasoninternational.com Owner’s Manual forma and Designer Microsilk -airMasseur Baths ® ® ® InsTallaTIOn, OPeraTIOn, anD MaInTenanCe If the carton shows sign of damage, inspect Damage to the unit during installation will not be covered by warranty and is the responsibility of the installer.
  • Page 2: Installation Instructions

    INSTALLATION INSTRUCTIONS INSTALLATION 4. Install the drain and overflow assembly to the bath shell according to the instructions provided with the See the USeR MAINTeNANCe INSTRUCTIONS section drain and position the bath in the area of intended of this owner’s manual, prior to installation, for humidity installation.
  • Page 3 INSTALLATION INSTRUCTIONS (cont.) Figure 3 10. Protect the acrylic bath surface from damage ® Note: Verify the MicroSilk Pump Assembly is the same during installation with a suitable material, i.e., unit that was provided for the bath being installed. The cardboard and/or plastic film.
  • Page 4 INSTALLATION INSTRUCTIONS (cont.) ® ® Caution: Confirm all tubing is fully engaged on 4. Clamp the MicroSilk Jet Line to the MicroSilk its respective barb and its clamp has secured the Discharge Barb using the clamp provided on the ® tubing to the barb.
  • Page 5 INSTALLATION INSTRUCTIONS (cont.) eLeCTRICAL ® 4. Standard/Premier edition MicroSilk -AirMasseur ® Control Box (120v). The MicroSilk generator unit electrical Power Supply: These instructions are written may be shipped separate from the bath. Follow the assuming 60Hz, 120v (or 240V for Signature Edition) ®...
  • Page 6 INSTALLATION INSTRUCTIONS (cont.) ® ® During installation, the control box bracket and controls Signature edition MicroSilk -AirMasseur Control ® must be positioned horizontally and located to permit Box. The MicroSilk generator unit may be shipped access for inspection and servicing. separate from the bath.
  • Page 7 INSTALLATION INSTRUCTIONS (cont.) CLeANING WATeR TeSTING Before finishing the installation, it is recommended that the 1. Remove all loose debris. Construction plaster or bath be water tested and the plumbing tested for leaks. excess grout can be removed with the use of a wood (edge) trowel.
  • Page 8: Control Box Connections

    MICROSILK -AIRMASSeUR CONTROL BOX CONNeCTIONS ® ® STANDARD eDITION MICROSILK -AIRMASSeUR ® ® ® ® Jason’s Standard Edition MicroSilk -AirMasseur system Figure 9 features the best in luxury bathing for the leisure bath industry. To assure that your bath functions properly, the ®...
  • Page 9 CONTROL BOX CONNECTIONS (cont.) THe MICROSILK CONTROL BOX Figure 10 ® ® The MicroSilk unit and water level sensor must be plugged into the proper receptacles for correct operation of the system. See Figure 10 for connections: (A) The ® power cord for the MicroSilk pump control box must be plugged into the proper GFCI dedicated circuit for the...
  • Page 10 OPeRATING INSTRUCTION, FeATUReS, AND CONTROLS INTRODUCTION Chromatherapy mood light, Automatic Ozone System that will be operated any time the blower is powered; a digital This manual contains all of the information needed for the control with LCD display window; low water and temperature proper installation and operation of your Jason MicroSilk ®...
  • Page 11 OPERATING INSTRUCTIONS, FEATURES, AND CONTROLS (cont.) Signature edition Automatic Purge Filling and Draining Twenty (20) minutes after the control has shut off and the Close the drain and fill the bath with water at least two (2) bath is completely drained, the blower will start again for a inches (50mm) above the jets.
  • Page 12 STANDARD AND PReMIeR eDITION MICROSILK -AIRMASSeUR TOUCHPAD ® ® Figure 12 AirMasseur On/Off, Modes ® Blower Speeds MICRO-AIRMASSEUR LED Light MicroSilk™ On/Off ® The Jason Standard and Premier Edition MicroSilk the blower speed once the blower is On. ® AirMasseur touchpad is used to access all of the ®...
  • Page 13 SIGNATURe eDITION MICROSILK -AIRMASSeUR TOUCHPAD ® Figure 13 For Diagnostic Functions Blower Speeds LED Light ® MicroSilk™ On/Off IR for Remote Display Panel LeD Light Icon The Jason Signature Edition MicroSilk -AirMasseur ® ® Hold the key for less than two (2) seconds to turn the lights digital touchpad is used to access all the functions of the two (2) control boxes used on the Jason Signature Edition Off or On.
  • Page 14: User Maintenance Instructions

    USeR MAINTeNANCe INSTRUCTIONS HUMIDITY SURFACe MAINTeNANCe Areas with minor scratches or dull surfaces can be Warning: Avoid high humidity levels in your home. restored by applying commercially available plastic Mold, mildew, fungi and bacteria which may be polish (i.e. Novus Plastic Polish No. 2, available at your harmful to health thrive in areas with continued high Jason dealer), followed by an application of acrylic paste humidity levels;...
  • Page 15: Troubleshooting Guide

    TROUBLe SHOOTING GUIDe If you believe the unit to be within the warranty period, you must contact Jason Customer Service: 1-800-255-5766 with the bath’s Product and Serial numbers before work is started. ALL WARRANTY RePAIRS MUST Be AUTHORIZeD BY JASON BeFORe WORK IS STARTeD. FOR SERVICE, ALWAYS CONTACT YOUR DEALER OR AUTHORIZED SERVICE CENTER WARNING: Always turn off power at the main electrical service panel when servicing the bath.
  • Page 16 airMasseur Blower system ® POssIBle Causes reCOMMenDeD aCTIOn sYMPTOMs a) Reset circuit breakers and check GFCI. Check fuses and a) No power to air bath unit. replace if bad. Blower system won’t operate. b) Blower Motor is not plugged in. b) Make sure plug is fully inserted into the outlet.
  • Page 17: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS InsTruCTIOns PerTaInIng TO The rIsK Of fIre, eleCTrIC shOCK, Or InJurY TO PersOns. This manual contains information and instructions for proper operation and maintenance of your hydrotherapy bath. Failure to follow these instructions could result in personal injury, electrical shock, or fire. warnIng: when using this unit, basic precautions should always be followed, including the following: reaD anD fOllOw all InsTruCTIOns CarefullY Danger:...
