3. SR868 smart relay receiver

The SALUS SR868 relay gives you control of the electrical heating. SR868 must be used in conjunction with the wireless RT series thermostats. The
thermostat communicates wirelessly with the SR868 smart plug receiver. The receiver should be supplied with 230VAC, the maximum load of the receiver
is 16A. Avoid installing the device in places directly exposed to water, moisture and air condensation.

3.1 Smart relay LED indication

Smart relay receiver has designed LED diode in the left upper corner. Here is description what an every single colour and diode means:
LED State
Red
Green
Red
8
On
Flash
On
2 x Flash
Flash alternately
and
Green
Flash in different sequence
Description
The relay is off.
The relay is in pairing mode.
The relay is on.
The relay is writing pairing code.
The relay is paired but lost link.
It indicates the software version after reboot.
