PRODUCT MANUAL
NeonMax 24V 85W
Product Description
Thank you for purchasing Solid Apollo's NeonMax 24V 85W!
Solid Apollo's NeonMax is a state of the art Neon LED light simulating
the effect and look of neon in a continuous well-balanced light. This next
generation bendable NeonMax projects a brutally bright light offering
optimum performance, energy efficiency, and effortless maintenance
over traditional glass neon.
This user guide is intended to instruct and guide any user on how to
properly cut the NeonMax to length, re-power with a new power cable,
and completely waterproof the connection.
Product Features
• 20ft Spool
• Flexible & Cuttable
• Side Bending
• Cut Points Every 2in
• Fully Dimmable
• Features a 6.6ft Waterproof Cable w/ Female Barrel Connector
• Low Voltage Product at 24V - 85W Per Spool
• Fully Waterproof, Rated at IP67
• Indoor / Outdoor Application
• Product Comes Ready to Plug & Play
• Perfect for Accent Lighting, Linear Lighting and In-Wall Lighting
Toll Free. 425-582-7533
www.SolidApollo.com
Andrew@SolidApollo.com
NeonMax 24V 85W
Manual Will Review
• Proper Cutting and Installation
• Waterproofing and
Configuration Process
• Technical Information
• Do's and Don'ts
™
page 1
Advertisement
Table of Contents
Related Manuals for Solid Apollo NeonMax 24V 85W
Summary of Contents for Solid Apollo NeonMax 24V 85W
- Page 1 Product Description Thank you for purchasing Solid Apollo’s NeonMax 24V 85W! Solid Apollo’s NeonMax is a state of the art Neon LED light simulating the effect and look of neon in a continuous well-balanced light. This next generation bendable NeonMax projects a brutally bright light offering optimum performance, energy efficiency, and effortless maintenance over traditional glass neon.
- Page 2 Tools & Accessories Required Sharp Metal Scissors or Shears (for cutting Neon at cut points) 15ft Waterproof LED Strip Extension Cable 5g Waterproofing Glue Cable End Cap for NeonMax 24V 85W Box Knife or Blade Soldering Iron Step 1: Locate the Cut Points Look on both sides of the NeonMax strip and find the side that has a thin transparent line in the middle of the strip.
- Page 3 PRODUCT MANUAL ™ Toll Free. 425-582-7533 NeonMax 24V 85W www.SolidApollo.com Andrew@SolidApollo.com Step 3: Exposing the Positive and Negative Contacts Once you have made your cut, notice that the positive and negative contacts are tucked inside the NeonMax Strip. Grab your box knife or blade and prepare to trim.
- Page 4 The example shown in Figure 8 utilizes Solid Apollo’ s 15ft Waterproof Cable which has a white strip running along the positive wire as an identifier.
- Page 5 PRODUCT MANUAL ™ Toll Free. 425-582-7533 NeonMax 24V 85W www.SolidApollo.com Andrew@SolidApollo.com Technical Information Dimmable : Watts per Spool : Minimum Cut : 2in (50mm) Max Power : Available Colors : Candle Light Warm White 2400K LED Type : SMD 2835...
