PRODUCT MANUAL
NeonArch 24V 90W
Product Description
Thank you for purchasing Solid Apollo's NeonArch 24V 90W!
Solid Apollo's NeonArch is a state of the art Neon LED light simulating
the effect and look of neon in a continuous well-balanced light. This next
generation bendable NeonArch projects a brutally bright light offering
optimum performance, energy efficiency, and effortless maintenance
over traditional glass neon.
This user guide is intended to instruct and guide any user on how to
properly cut the NeonArch to length, re-power with a new power cable,
and completely waterproof the connection.
Product Features
• 16.4ft Spool
• Flexible & Cuttable
• Top Bending
• Cut Points Every 1.3in
• Fully Dimmable
• Features a 6.6ft Waterproof Cable w/ Female Barrel Connector
• Low Voltage Product at 24V - 90W Per Spool
• Fully Waterproof, Rated at IP67
• Indoor / Outdoor Application
• Product Comes Ready to Plug & Play
• Perfect for Accent Lighting, Linear Lighting and In-Wall Lighting
Toll Free. 425-582-7533
www.SolidApollo.com
info@SolidApollo.com
NeonArch 24V 90W
Manual Will Review
• Proper Cutting and Installation
• Waterproofing and
Configuration Process
• Technical Information
• Do's and Don'ts
™
page 1
Advertisement
Table of Contents
Related Manuals for Solid Apollo NeonArch 24V 90W
Summary of Contents for Solid Apollo NeonArch 24V 90W
- Page 1 Product Description Thank you for purchasing Solid Apollo’s NeonArch 24V 90W! Solid Apollo’s NeonArch is a state of the art Neon LED light simulating the effect and look of neon in a continuous well-balanced light. This next generation bendable NeonArch projects a brutally bright light offering optimum performance, energy efficiency, and effortless maintenance over traditional glass neon.
- Page 2 Tools & Accessories Required Sharp Metal Scissors or Shears (for cutting Neon at cut points) 15ft Waterproof LED Strip Extension Cable 5g Waterproofing Glue Cable End Cap for NeonArch 24V 90W Box Knife or Blade Soldering Iron Step 1: Locate the Cut Points The cut points on the NeonArch are located on the bottom of the light under the Ultra High Bond (UHB) tape.
- Page 3 PRODUCT MANUAL ™ Toll Free. 425-582-7533 NeonArch 24V 90W www.SolidApollo.com info@SolidApollo.com Step 3: Exposing the Positive and Negative Contacts Once you have made your cut, notice that the positive and negative contacts are tucked inside the NeonArch body. Grab your box knife or blade and prepare to trim.
- Page 4 The example shown in Figure 8 utilizes Solid Apollo’ s 15ft Waterproof Cable which has a white strip running along the positive wire as an identifier.
- Page 5 PRODUCT MANUAL ™ Toll Free. 425-582-7533 NeonArch 24V 90W www.SolidApollo.com info@SolidApollo.com Technical Information Dimmable : Watts per Spool : Minimum Cut : 1.3in (33mm) Max Power : Available Colors : Candle Light Warm White 2400K LED Type : SMD 2835...
