USER MANUAL
Neon LED Configuration
Product Description
Neon LED comes ready for customization to fit almost any lighting project. This user guide is intended to instruct anyone on how to re-
power Neon LED, add joiners and an endcap.
This user manual can be used when extra Neon LED has been left over from an installation or if extra Neon LED needs to be added, or
during an installation where unexpected gaps or jumps are suddenly required. Basically every part of making a fully waterproof and
long lasting installation is covered in this user manual.
Main Functions:
Power Adapter: For re-powering a piece of Neon LED
Joiner: Used for reconnecting Neon LED
Endcap: For adding a waterproof seal to the end of Neon LED
Mounting Bracket: For firmly attaching Neon LED
This manual reviews:
• Entire waterproof and configuration process
• How to add a power adapter
• How to install a joiner
• How to add the endcap
• How to install the mounting bracket
Technical Features:
Operating Voltage: 120V AC
Watts Per Foot: 2.42W
Cut Points: Every 19.69 inches
36 LED's per foot
Neon LED
Toll Free: 866.592.3873
Email: sales@solidapollo.com
www.SolidApollo.com
Page 1
