PRODUCT MANUAL
RGB NeonMini 24V 60W
Product Description
Thank you for purchasing Solid Apollo's RGB NeonMini 24V 60W!
Solid Apollo's RGB NeonMini is a state of the art Neon LED light
simulating the effect and look of neon in a continuous well-balanced
light. This next generation bendable RGB NeonMini projects a brutally
bright light offering optimum performance, energy efficiency, and
effortless maintenance over traditional glass neon.
This user guide is intended to instruct and guide any user on how to
properly cut the RGB NeonMini to length, re-power with a new power
cable, and completely waterproof the connection.
Product Features
• 20ft Spool
• Flexible & Cuttable
• Side Bending
• Cut Points Every 2in
• Fully Dimmable
• Features a 6.6ft Waterproof Cable w/ Female Barrel Connector
• Low Voltage Product at 24V - 60W Per Spool
• Fully Waterproof, Rated at IP67
• Indoor / Outdoor Application
• Product Comes Ready to Plug & Play
• Perfect for Accent Lighting, Linear Lighting and In-Wall Lighting
Toll Free. 425-582-7533
www.SolidApollo.com
Andrew@SolidApollo.com
RGB NeonMini 24V 60W
Manual Will Review
• Proper Cutting and Installation
• Waterproofing and
Configuration Process
• Technical Information
• Do's and Don'ts
™
page 1
Advertisement
Related Manuals for Solid Apollo RGB NeonMini
Summary of Contents for Solid Apollo RGB NeonMini
- Page 1 Product Description Thank you for purchasing Solid Apollo’s RGB NeonMini 24V 60W! Solid Apollo’s RGB NeonMini is a state of the art Neon LED light simulating the effect and look of neon in a continuous well-balanced light. This next generation bendable RGB NeonMini projects a brutally bright light offering optimum performance, energy efficiency, and effortless maintenance over traditional glass neon.
- Page 2 Proper Cutting and Installation This section will guide you on how to cut the RGB NeonMini, install a power/extension cable, and add an end cap for a complete, fully waterproof connection. Please note, for outdoor or high humidity applications, we recommend using waterproofing glue for all connections and a drying time of at least 24 hours before installing or using the RGB NeonMini.
- Page 3 Cable End Cap (see Figure 5). Leaving the positive and negative wires too long will not properly seal the connection and will cause the RGB NeonMini to fail over time due to debris and exposure to other damaging elements. See Figure 6 for proper connection.
- Page 4 On the strip, you can identify each contact by looking for the icons printed net to the contacts (see Figure 7). The example shown in Figure 8 utilizes Solid Apollo’ s 15ft RGB Waterproof Cable which has red, green, blue, and white stripes running along the RGB and positive wires respectively as an identifier.
-
Page 5: Technical Information
2. Don’t - Keep in mind that the RGB NeonMini is side bending (left to right) in the opposite direction of the light output and not top bending (up and down). Bending the RGB NeonMini vertically could split the contacts causing the unit to fail.
