Bauhn Actios ATVS65-0716 Quick Manual

65" 4K Ultra High Definition LED LCD Smart TV
Model number: ATVS65-0716
GETTING STARTED
1
PARTS LIST
In the box you will find:
1 x 65" (165cm) 4K Ultra High Definition LED LCD Smart TV
1 x Remote Control
2 x AAA Activ Energy Batteries (not pictured)
1 x AV Cable (not pictured)
2 x Stand Bases (including screws)
1 x Instruction Manual
1 x Getting Started guide
WHAT YOU WILL NEED
A Phillips-Head Screwdriver (for stand installation)
Antenna Cable
Broadband Internet Connection (to access Smart TV and Catch Up TV features)
(Optional) Wireless keyboard and mouse (for easy smart app interactivity and web browsing experience)
2
CONNECTIONS
1 LAN Input
2 HDMI 2.0 Inputs
3 Headphones Output
4 Coaxial S/PDIF Output
5 Optical S/PDIF Output
6 Video Input (Composite)
7 Antenna Input
8 USB 3.0 Input
9 Y/Pb/Pr Input (Component)
10 USB 2.0 Input
3
CONNECT TO POWER
1 Install the stand (see page 5 of the instruction
manual).
2 Connect the antenna cable to the ANT socket of
the TV.
3 Connect RJ45 LAN cable to the LAN socket of the
TV (for wired Internet connection); or turn on your
Wi-Fi modem/router (for Wi-Fi Internet connection).
4 Insert batteries into the remote control.
5 Connect the TV power cord into the mains power
socket and turn on the mains power.
6 Press the button on the remote control to turn
on the power to the unit. The standby light will turn
blue and the TV screen will display the initial setup.
4
EASY SETUP SCREEN
The On-Screen Display (OSD) gives you
easy instructions for setting up the unit.
Follow the OSD instructions to connect
the TV to the Internet and scan TV
channels. Please refer to the Instruction
Manual for detailed information.
