Installation With Single Oven; Under-Cabinet Mounting - GE Monogram ZEM200BF Installation Instructions Manual

Refer to diagram at
With single
right for dimensions
oven
when installing above
a Monogram single
oven.
Note: Trim kit JX827 is
required for installation above
a single oven.
Within opening of appropriate dimensions:
• Install a level base of plywood:
• 3/8" thick (min.) plywood must be sup-
• Finished floor must support a minimum of
• Assemble JX827 accessory kit, refer to
These microwve ovens may be installed under
Under-cabinet
virtually any cabinetry and is supplied with
mounting
all hardware necessary for under-cabinet
installation. The cabinet must be capable of
supporting the items in the cabinet plus an
additional 90 pounds from the bottom. Refer
to "Advance Planning" for more details.
– Flush with lower edge of opening.
– Entirely covering floor of opening.
ported by 2" x 4" or 1" x 2" equivalent
runners on all four sides.
100 pounds.
"Installation" for details.
Installation Preparation
Micr owav e Oven
24-7/8" 1/16"
15" 1/16"
Per Oven
Requirement
Door
Front of Cabinet
Side of
Microwave
Bracket
5
