Instruction and parts manual
REE2-17, 24
RIE2-17, 19
REE4-17
IKEA
Manual Nº:
WO19021504ENG
Publishing date:
22-06-2017 (original manual)
Index
Definitions ............................................................................... 2
Note .......................................................................................... 2
Quality Standards/Norms and Directives .......................... 2
Safety ....................................................................................... 3
Identification ........................................................................... 4
Assembly ................................................................................. 5
Working with KOOI-REACHFORKS® .................................. 6
Maintenance Schedule......................................................... 6
Wear ......................................................................................... 7
Taking goods from the racking ............................................ 8
Loading goods into the racking ........................................... 9
Instructions for Replacement of Sleeve ............................ 10
Replacement of Hydraulic Parts ......................................... 11
Troubleshooting ...................................................................... 14
Replacement parts list REE2 ................................................ 15
Replacement parts list sleeves REE2 ................................. 16
Language: ENG
Revision: 04
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Meijer KOOI-REACHFORK REE2-17
Summary of Contents for Meijer KOOI-REACHFORK REE2-17
-
Page 1: Table Of Contents
Instruction and parts manual REE2-17, 24 RIE2-17, 19 REE4-17 IKEA Manual Nº: WO19021504ENG Language: ENG Publishing date: 22-06-2017 (original manual) Revision: 04 Index Definitions ................2 Note ..................2 Quality Standards/Norms and Directives ......2 Safety ..................3 Identification ................4 Assembly ................. -
Page 2: Definitions
Please note that information in this manual may be changed at any time without prior notice and that it may contain tech- nical inaccuracies and typing errors. Meijer Handling Solutions B.V. makes every effort to avoid errors in this manual, but cannot guarantee this. -
Page 3: Safety
Safety Warning: Caution: Do not ride on the KOOI-REACHFORKS® or on When leaving the forklift the engine must be the load. switched off and the handbrake applied. Warning: Caution: Do no walk or stand under the KOOI-REACH- Bear in mind the space above and beneath the FORKS®. -
Page 4: Identification
Identification Type plate legend: Mounting type description of KOOI-REACHFORKS®:... -
Page 5: Assembly
Assembly The KOOI-REACHFORKS® type plates are stamped with an ‘L’ and an ‘R’. Mount the KOOI- REACHFORKS® on the left (L) and right (R) as viewed from the forklift operator’s seat. Slide the KOOI-REACHFORKS® onto the carriage plate. Connect the KOOI-REACHFORKS® to the hydraulic system via the flow divider (1). -
Page 6: Working With Kooi-Reachforks
Working with KOOI-REACHFORKS® To minimise wear, avoid allowing the KOOI-REACHFORKS® to come in contact with the ground during operation . In order to reduce wear: • The chains in the forklift mast can be shortened so that the KOOI-REACHFORKS® cannot reach the ground. •... -
Page 7: Wear
Wear The thickness of Wear Strips (1) may not be less than The inner fork must be replaced when S1 is 5% thinner 1.5 mm (1/16”). When Wear Strips (1) have worn to this than S2. See point 7 of the Maintenance Schedule. thickness, replace them or fill with spacers (2) (Art. -
Page 8: Taking Goods From The Racking
Taking goods from the racking 1. Position the lift truck straight in front of the racking 3. drive straight backwards and only then lower the goods in the lowest possible position. 2. Lift the forks to the right position to take out the goods. 4. -
Page 9: Loading Goods Into The Racking
Loading goods into the racking 1. Position the lift truck straight in front of the racking with 3. Drive straight backwards and only then lower the forks the load still in the lowest position. in the lowest possible position. 2. Lift the load and place the goods inside the racking. 4. -
Page 10: Instructions For Replacement Of Sleeve
Instructions for Replacement of Sleeve Position the KOOI-REACHFORKS® at hip height, tilt the mast of the forklift slightly forward and remover the key from the ignition switch of the forklift. Warning: Do not carry out maintenance work on the KOOI-REACHFORKS® whilst there is pressure in the hydraulic system (remove key from forklift ignition switch). -
Page 11: Replacement Of Hydraulic Parts
Do not use a burner in an area not equipped/in- ratchet. Tools required: Cylinder head spanner, 1/2’’ ratchet. tended for his purpose because of fire hazard. *Cylinder head spanners are only available from Meijer Handling Solutions B.V. (Art. Nº RE0058049). - Page 12 Slide the (new) cylinder head (5) onto the piston rod (10). When piston (9) is removed, the cylinder head (5) can be removed, should it need to be replaced. Caution: Do not damage the cylinder head seals (5) during assembly as this can result in leakage. Pay par- ticular attention when the sliding cylinder head (5) over the thread (10) of the piston rod.
- Page 13 1/2” ratchet. Cylinder diameter (mm) Torque (Nm) Finally, follow step 5 of the chapter on ‘Assem- bly’. *Cylinder head spanners are only available from Meijer Handling Solutions B.V. (Art. Nº RE0058049). See www.loctite.com See www.kroon-oil.com Caution: Do not damage the piston or cylinder head seals...
-
Page 14: Troubleshooting
Troubleshooting Observation Symptom Possible Cause Possible Solution Bent piston rod Replace piston rod and Oil leak between cylinder Scratched/damaged piston cylinder head head and piston rod Leaking piston seal Replace cylinder head Oil leak between cylinder Leaking O-Ring Replace O-ring head and fork blade. -
Page 15: Replacement Parts List Ree2
Replacement parts list REE2 / RIE2 / REE4 Pos. Nº Description Article Nº Number of parts per set and type of forks REE4-17 REE2-17 REE2-24 Cylinder head spanner REE2 RE0058049 Piston with sealing RE Ø25 (for piston rod Ø16) RE2008000 Piston seal RE Ø25 (for piston rod Ø16) RE0015000 Wear strip plastic 80x25x4.5... -
Page 16: Replacement Parts List Sleeves Ree2
Replacement parts list sleeves REE2 / RIE2 / REE4 REE 17 type I REE 17 type II REE 24 type I REE 24 type II Wear plates REE types RIE 17 / 19 type I RIE 17 / 19 type II Description Article Nº...
