SONOMA CORONADO DECO BACK TABLE ASSEMBLY INSTRUCTIONS
PART LIST
A
B
C
D
E
F
G
SAVE THESE INSTRUCTIONS
STYLE #: 71SRRSL09
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
FIGURE
QUANTITY
1 PC
4 PCS
1 PC
8 PCS + 1 PC
8 PCS + 1 PC
16 PCS + 1 PC
1 PC
DESCRIPTION
TOP
LEG
LEG CONNECTOR
SHORT BOLT
(M6*15MM)
LONG BOLT
(M6*25MM)
FLAT WASHER
ALLEN WRENCH
Page 1/3
Advertisement
Table of Contents
Related Manuals for Kohl's 71SRRSL09
Summary of Contents for Kohl's 71SRRSL09
- Page 1 SAVE THESE INSTRUCTIONS SONOMA CORONADO DECO BACK TABLE ASSEMBLY INSTRUCTIONS STYLE #: 71SRRSL09 ASSEMBLE ON A FLAT, PROTECTED SURFACE. PART LIST FIGURE QUANTITY DESCRIPTION 1 PC 4 PCS 1 PC LEG CONNECTOR SHORT BOLT 8 PCS + 1 PC (M6*15MM)
- Page 2 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SRRSL09 STEP 1 A. PLACE TOP (A) UPSIDE DOWN ON A FLAT, PROTECTED SURFACE. B. CONNECT LEGS (B) TO TOP (A) WITH SHORT BOLTS (D) AND FLAT WASHERS (F) USING ALLEN WRENCH (G). DO NOT TIGHTEN COMPLETELY.
- Page 3 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SRRSL09 ** WE RECOMMEND THAT YOU SAVE THE ALLEN WRENCH (G) AND PERIODICALLY TIGHTEN ALL BOLTS. WEIGHT LIMIT 110 LBS CARE AND CLEANING WIPE CLEAN WITH A MILD SOAP AND WATER SOLUTION, RINSE WITH CLEAN WATER, AND DRY THROUGHLY.
