ENTRYPASS EP.NE4800 Wiring Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
EP.NE4800 WIRING GUIDE
Version: 1.01
Last Updated: 11-04-2017
ENTRYPASS TECHNICAL – WIRING GUIDE
Copyright © Entrypass Corporation

Advertisement

loading
Need help?

Need help?

Do you have a question about the EP.NE4800 and is the answer not in the manual?

Questions and answers

Related Manuals for ENTRYPASS EP.NE4800

Summary of Contents for ENTRYPASS EP.NE4800

  • Page 1 EP.NE4800 WIRING GUIDE Version: 1.01 Last Updated: 11-04-2017 ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 2 For existing site, P1 will detect its card database to determine 6 or 10 digits; For new site, user can change the digits as long as the card database is empty. Please refer to separate EntryPass Platform1 User Manual for detail operation help. The Official EntryPass Platform1 User Manual can be downloaded from our website under “Download”...

  • Page 3: Before You Begin

    Should you need additional information, please call our Technical Support Help desk, Monday to Friday 9:00 AM to 6:00 PM (GMT +8:00) Method Details Phone + 60 (3) - 8068 1929 Fax + 60 (3) - 8068 1922 Internet www.entrypass.net Email support@entrypass.net ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...

  • Page 4: Considerations Prior To Installation

    Considerations Prior to Installation Preparing Your EntryPass Controllers EntryPass controller contains numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Thus, prior to installation, please follow the instruction below: •Observe precautions while handling the circuit board assembly by using proper grounding straps and handling precautions at all •Visually ensure no onboard parts is broken, damage or contains burn mark...
  • Page 5 NE4800 ( HCB with ComGateway board ) RESET COLD ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 6 ComGateway Component Description Reset MCU ( WIE.485 ) Reset MCU ( POB ) MCU ( WIE.485 ) Onboard Power LED MCU ( POB ) COM Rx/Tx LEDs RESET COLD ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 7 HCB Controller (On Bottom) : BUZ ON RLY1 RLY2 NULL: BUZ OFF ADDR RESET 1 -2: 12 V 2 -3: 5V OUT1 OUT 2 2 3 4 5 COLD GND-ETH LOWER CONNECTOR ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 8 - POB 1 RS485 (+) Connection - WIE.485 1 RS485 (+) Connection - POB 1 RS485 (-) Connection - WIE.485 1 RS485 (-) Connection Each POB RS485 connection can support Max. 4 unit POB controller ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...

  • Page 9: Power Supply Connector

    BAT/BS (Backup Battery Monitoring) point will monitor the backup battery voltage which will supply power to the board when AC power is cut off The minimum voltage for cutoff while using backup battery is 10V ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 10 Power Supply Unit Specification ENTRYPASS Power Supply Unit Specification: • Switching Power Supply • 12V DC • 3 Amp (Minimum) ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 11 NC31 NO18 COM18 NC18 NO20 COM20 NC20 NO22 COM22 NC22 NO24 COM24 NC24 NO26 COM26 NC26 NO28 COM28 NC28 NO30 COM30 NC30 NO32 COM32 NC32 Digital Output Connector 2 Terminator Jumper ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 12 - Relay 15 Common Input COM7 - Relay 7 Common Input NO15 - Relay 15 Normally Open Connection - Relay 7 Normally Open Connection - Inputs Ground - Input 2 - Input 1 ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 13 - Relay 16 Common Input COM8 - Relay 8 Common Input NO16 - Relay 16 Normally Open Connection - Relay 8 Normally Open Connection - Inputs Ground - Input 4 - Input 3 ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 14 - Relay 23 Normally Open Connection COM31 - Relay 31 Common Input COM23 - Relay 23 Common Input NC31 - Relay 31 Normally Close Connection NC23 - Relay 23 Normally Close Connection ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 15 - Relay 24 Normally Open Connection COM32 - Relay 32 Common Input COM24 - Relay 24 Common Input NC32 - Relay 32 Normally Close Connection NC24 - Relay 24 Normally Close Connection ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...

  • Page 16: Power Supply Connection

    BT.MON (Backup Battery Monitoring) point will monitor the backup battery voltage which will supply power to the board when AC power is cut off The minimum voltage for cutoff while using backup battery is 10V ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 17 COM6 COM8 NO26 NC24 COM24 NO24 NC22 COM22 NO22 NC20 COM20 NO20 NC18 COM18 NO18 Lower Connector Keyswitch can only be connected IN1 , IN2 , IN3 and IN4 to GND ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 18 Connecting Power Supply to NE4800 and POB controller Power Supply ENTRYPASS RESET COLD Power Supply ENTRYPASS ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 19 The default DIP switch configuration of the POB controller is 1 ( ON ) For POB Number 1 For POB Number 2 For POB Number 3 For POB Number 4 ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 20 The number in ( ) is the address of each individual switch of the dip switch Example: To obtain Address 11, 1 + 2 + 8 = 11, So just switch on switch 1, 2, 4 ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 21 1 POB controller is connected. Is advisable to connect a jumper at JP3 as terminator on last POB controller. Remove the RESET COLD jumper for the rest of POB. POB1 POB2 POB3 POB4 ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 22 Connecting 16 units POB controller (512 Floors) C4+C4- C2+C2- C1+C1- Floor 385 Floor 257 Floor 129 Floor 001 POB13 POB9 POB5 POB1 POB14 POB10 POB6 POB2 POB15 POB11 POB7 POB3 POB16 POB12 POB8 POB4 ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 23 WIE.485 120 Ohm Resistor C1 – C2 – Vout Vout +12V EARTH BATT Note: Is advisable connect 120 Ohm resistor on all WIE.485 board for RS485 signal termination. ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 24 Connecting the WIE.485 to NE4800 controller RESET COLD Power Supply ENTRYPASS C2 – C1 – Vout Vout ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 25 120 Ohm resistor on all ENTRYPASS WIE.485 board for RS485 signal termination. RESET COLD 120 Ohm Resistor C1 – C2 – Vout Vout Power Supply +12V GND EARTH NO1 BATT ENTRYPASS ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 26 Put the jumper cap at JP5 2-3 to output 5VDC at Vout Put the jumper cap at JP6 1-2 to output 12VDC at Vout Put the jumper cap at JP6 2-3 to output 5VDC at Vout ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 27 3) Gateway: 0.0.0.0 4) Server IP address: 192.168.1.254 To change the network setting, simply logon to the web server. The distance from NE4800 controller to network switch should not more than 100 meter ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 28 4. Release COLD switches when a long beeping sound heard Advisable to perform cold start for the first time you turn on the power The buzzer will only beep if jumper is placed on JP2 1-2 ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 29 192.168.1.254 and Port to 2020 For the network controller support AES Encryption feature, factory default will disable the AES feature The buzzer will only beep if jumper is placed on JP2 1-2 ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 30 2. Press RESET Switch and Release RESET switch AES setting in the controller will be reset If the controller is connected with AES enabled Platfrom1, Platfrom1 will sync and update AES setting with the controller ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 31 Lift Application System Overview NE4800 WIE.485 Cat-5 Cat-5 Network Switch EntryPass Platform1 Access Control System Reader 2 Reader 1 Existing Lift Controller Panel Floor 1 - 16 KeySwitch Floor 17 - 32 ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
  • Page 32 Connecting to EntryPass Platform1 Access Control System Before you begin to connect to the EntryPass Platform1 Access Control System, please make sure all the wiring connection is correct. On the NE4800, please make sure the following setting has been done: To configure the EP.NE4800...

  • Page 33: Cabling Information

    WIE.485 to Reader Wiegand (100 ft) Twisted Pair 1000m 22 AWG, 2 Pairs, Shielded & NE4800 to POB RS485 (3000 ft) Twisted Pair POB to Keyswitch Contact 22 AWG, 1 Pair (100 ft) ENTRYPASS TECHNICAL – WIRING GUIDE Copyright © Entrypass Corporation...
