GE Profile Harmony PTDS850EM Dimensions And Installation Information

PTDS850EM/PTDS855EM
GE Profile Harmony
Dimensions and Installation Information (in inches)
Exhaust Options: 4-way via rear, right, left
and bottom. Dryer is shipped exhausted
to the rear. Right, left or bottom exhaust
requires a conversion kit.
NEMA Receptable codes:
3-prong dryer cord/30A/4' long (cat #WX9X2)
is for NEMA10-30R receptable
4-prong dryer cord?30A/4' ong (cat #WX9X18)
is for NEMA14-30R receptacle
Circuit Requirements: An individual properly-
grounded branch circuit, protected by a 30
amp circuit breaker or a time-delay fuse is
required.
Electric Dryer Rating: 240V, 6000W, 28.5A,
60Hz
Note: Dryer wall outlet must be located within
36" of service cord entry and accessible when
dryer is mounted in position.
Installation Information: For complete
information, see installation instructions
packed with your dryer.
For answers to your Monogram, GE Profile
®
GE ® appliance questions, visit our website at
ge.com or call GE Answer Center
®
800.626.2000.
GE Profile Harmony Dryer
7.3 Cu. Ft. Stainless Steel Capacity Electric Dryer
™
21.25
or
™
service,
29
27.25
3.5
38
Side View
27
45
13
3
2.5
Rear View
Specification Revised 12/10
3.5
Listed by
Underwriters
Laboratories
270174
