  • Page 2 ECAMIP501/ECAMIP501B·Quick Start Guide Quick Start Guide About this Manual The Manual includes instructions for using and managing the Product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
  • Page 3 ECAMIP501/ECAMIP501B·Quick Start Guide NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF OUR COMPANY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS. YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR...

  • Page 4: Regulatory Information

    ECAMIP501/ECAMIP501B·Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 5 ECAMIP501/ECAMIP501B·Quick Start Guide FCC Conditions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.

  • Page 6: Safety Instruction

    ECAMIP501/ECAMIP501B·Quick Start Guide or to a designated collection point. For more information see: www.recyclethis.info Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss.
  • Page 7 ECAMIP501/ECAMIP501B·Quick Start Guide Warnings ● For device with this sticker, this device is intended for installation in a restricted access location, access can only be gained by service persons or by users who have been instructed about the reasons for the restrictions applied to the location and about any precautions that shall be taken.
  • Page 8 ECAMIP501/ECAMIP501B·Quick Start Guide ● Please make sure that the plug is firmly connected to the power socket. When the product is mounted on wall or ceiling, the device shall be firmly fixed. ● If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center.
  • Page 9 ECAMIP501/ECAMIP501B·Quick Start Guide ● To avoid heat accumulation, good ventilation is required for operating environment. ● Keep the camera away from liquid while in use. ● While in delivery, the camera shall be packed in its original packing, or packing of the same texture.

  • Page 10: Appearance Description

    ECAMIP501/ECAMIP501B·Quick Start Guide 1 Appearance Description The overview of the cameras are shown as the figures below. Type I Camera Overview Type II Camera Overview Table 1-1 Description Description Camera Body Enclosure Mounting Base...
  • Page 11 ECAMIP501/ECAMIP501B·Quick Start Guide Description Lock Button Network Cable Power Cord Notes: Only certain models support memory card installation and reset ⚫ function. Power on the camera when pressing the RESET button, and ⚫ press button for another 10 seconds to restore the default settings, including the user name, password, IP address, port No., etc.

  • Page 12: Installation

    ECAMIP501/ECAMIP501B·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12 VDC or PoE, make sure your power supply matches with your camera.
  • Page 13 ECAMIP501/ECAMIP501B·Quick Start Guide Expose the Memory Card Slot 2. Loosen the screws to remove the memory card slot cover. 3. Insert the memory card into the slot, and push to get it mounted. Memory Card Reset Button Memory Card Slot Install the Memory Card 4.

  • Page 14: Ceiling Mounting

    ECAMIP501/ECAMIP501B·Quick Start Guide 2.2 Ceiling Mounting Before you start: Type I and Type II camera both support the ceiling mounting and the steps are similar. Here takes type II as an example to describe the steps. Steps: Disassemble the camera by pressing the button on the camera.
  • Page 15 ECAMIP501/ECAMIP501B·Quick Start Guide 54.3 3-Φ4.5 Φ125 14.5 Figure 2-4 The Drill Template Drill the screw holes or the cable hole in the ceiling according to the drill template. Note: Drill the cable hole if adopting ceiling outlet to route the cable.
  • Page 16 ECAMIP501/ECAMIP501B·Quick Start Guide Note: In the supplied screw package, both self-tapping screws, and ⚫ expansion bolts are contained. If the ceiling is cement, expansion bolts are required to fix the ⚫ camera. If the ceiling is wooden, self-tapping screws are required.

  • Page 17: Wall Mounting

    ECAMIP501/ECAMIP501B·Quick Start Guide Power on the camera, and set the network configuration. For details, refer to 3 Set the Network Camera over the LAN and 4 Access via Web Browser. Adjust the surveillance angle. Adjust Surveillance Angle 1). Hold the camera body and rotate the enclosure to adjust the pan angle [0°...
  • Page 18 ECAMIP501/ECAMIP501B·Quick Start Guide Steps: 1. Disassemble the camera by pressing the button on the camera. Disassemble the Camera 2. Drill screw holes in the wall according to the holes of the bracket and install the bracket to the wall with screws.

  • Page 19: Mounting With Junction Box

    ECAMIP501/ECAMIP501B·Quick Start Guide Install the Mounting Base to the Bracket 4. Repeat steps 5 to 9 of 2.2 Ceiling Mounting to complete the installation. 2.4 Mounting with Junction Box Before you start: ● Type I and Type II both support mounting with junction box and the steps are similar.
  • Page 20 ECAMIP501/ECAMIP501B·Quick Start Guide Disassemble the Camera 2. Paste the supplied drill template to the desired mounting position. 62.6 4-Φ6 Φ130 Φ30 Drill Template 3. Drill the screw holes according to the drill template. 4. (Optional) If you want to route the cables inside the wall, drill a cable hole in the wall according to the adapter plate.
  • Page 21 ECAMIP501/ECAMIP501B·Quick Start Guide Fix Mounting Base on the junction box's Cover 6. Secure the junction box's body on the wall with screws. Secure the Junction Box's Body on the Wall 7. Combine the junction box's cover with its body with supplied...

  • Page 22: Mounting With Inclined Base

    ECAMIP501/ECAMIP501B·Quick Start Guide Combine the Junction Box's Cover with its body 8. Repeat steps 5 to 9 of 2.2 Ceiling Mounting to complete the installation. 2.5 Mounting with Inclined Base Before you start: ● Type I and Type II both support mounting with inclined base and the steps are similar.
  • Page 23 ECAMIP501/ECAMIP501B·Quick Start Guide 2. Paste the inclined base's drill template to the wall. 3. Drill screw holes and the cable hole (optional) on the wall according to the supplied drill template. Note: Drill the cable hole, when adopting ceiling outlet to route the cable 62.6...

  • Page 24: Waterproof Measures

    ECAMIP501/ECAMIP501B·Quick Start Guide Fix the Inclined Base's boy on Ceiling/Wall 6. Combine inclined base's cover with its body with screws. Combine the Cover with the Body 7. Repeat steps 5 to 9 of 2.2 Ceiling Mounting to complete the installation.
  • Page 25 ECAMIP501/ECAMIP501B·Quick Start Guide 2.6.1 Install Network Cable Waterproof Jacket Align Figure 2-21 Install Waterproof Jacket Steps: 1. Feed the network cable through ① and ③ in order. 2. Fix ② on the network cable between ① and ③. 3. Place ⑤ onto the end of ⑥, and plug the RJ45 male connector into RJ45 female connector.
  • Page 26 ECAMIP501/ECAMIP501B·Quick Start Guide Waterproof Cables...
  • Page 27 ECAMIP501/ECAMIP501B·Quick Start Guide 3 Set the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 28: Activate The Camera

    ECAMIP501/ECAMIP501B·Quick Start Guide Connect via a Switch or a Router 3.2 Activate the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via web browser, activation via SADP, and activation via client software are all supported.
  • Page 29 ECAMIP501/ECAMIP501B·Quick Start Guide Notes: The default IP address of the camera is 192.168.1.64. ⚫ The computer and the camera should belong to the same ⚫ subnet. For the camera enables the DHCP by default, you need to use ⚫ the SADP software to search the IP address.
  • Page 30 ECAMIP501/ECAMIP501B·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 31 ECAMIP501/ECAMIP501B·Quick Start Guide Select inactive device. Input and confirm password. SADP Interface Note: The SADP software supports activating the camera in batch. Refer to the user manual of SADP software for details. 3. Create and input the new password in the password field, and confirm the password.

  • Page 32: Modify The Ip Address

    ECAMIP501/ECAMIP501B·Quick Start Guide Note: You can enable the Guarding Vision service for the device during activation. Refer to Chapter 5.1 for detailed information. 4. Click Activate to start activation. You can check whether the activation is completed on the popup window.
  • Page 33 ECAMIP501/ECAMIP501B·Quick Start Guide Modify the IP Address Note: You can enable the Guarding Vision service for the device during activation. Refer to Chapter 5.1 for detailed information. 4. Input the admin password and click Modify to activate your IP address modification.

  • Page 34: Access Via Web Browser

    ECAMIP501/ECAMIP501B·Quick Start Guide 4 Access via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and...
  • Page 35 ECAMIP501/ECAMIP501B·Quick Start Guide 4. Click Login. Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.

  • Page 36: Operate Via Guarding Vision App

    ECAMIP501/ECAMIP501B·Quick Start Guide 5 Operate via Guarding Vision App Purpose: Guarding Vision is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so on. Note: Guarding Vision service is not supported by certain camera models.
  • Page 37 ECAMIP501/ECAMIP501B·Quick Start Guide “Privacy Policy” Service” Verification Code Setting (SADP) Note: The verification code is required when you add the camera to Guarding Vision app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. 5.1.2 Enable Guarding Vision Service via Web Browser Before you start: You need to activate the camera before enabling the service.
  • Page 38 ECAMIP501/ECAMIP501B·Quick Start Guide Steps: 1. Access the camera through web browser. Refer to Chapter 4. 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access. Guarding Vision Platform Access Configuration (Web) 3. Select Platform Access Mode as Guarding Vision.

  • Page 39: Guarding Vision Setup

    ECAMIP501/ECAMIP501B·Quick Start Guide Note: The verification code is required when you add the camera to Guarding Vision app. 7. Save the settings. 5.2 Guarding Vision Setup Steps: 1. Download and install the Guarding Vision app by searching "Guarding Vision" in App Store or Google Play 2.
  • Page 40 ECAMIP501/ECAMIP501B·Quick Start Guide Note: After the camera connects to the network, please wait one minute before any operation on the camera using Guarding Vision app. 2. In the Guarding Vision app, tap "+" on the upper-right corner and then scan the QR code of the camera to add the camera.

  • Page 41: Initialize The Memory Card

    ECAMIP501/ECAMIP501B·Quick Start Guide Note: For detailed information, refer to the user manual of the Guarding Vision app. 5.4 Initialize the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it.
  • Page 42 Made in PRC Imported by Velleman Group nv Legen Heirweg 33, 9890 Gavere, Belgium www.velleman.eu...
