Summary of Contents for Velleman EtiamPro ECAMIP701
-
Page 2: Regulatory Information
ECAMIP701·Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. -
Page 3: Safety Instruction
ECAMIP701·Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death. Cautions: Neglecting any of the cautions may cause injury or equipment damage. - Page 4 ECAMIP701·Quick Start Guide Cautions Fire Prevention No naked flame sources, such as lighted candles, should be placed on the equipment. The serial port of the equipment is used for debugging only. Hot Surface CAUTION: Hot parts! Burned fingers when handling the parts. This sticker is to indicate that the marked item can be hot and should not be touched without taking care.
- Page 5 ECAMIP701·Quick Start Guide Maintenance If the product does not work properly, please contact your dealer or the nearest service center. We shall not assume any responsibility for problems caused by unauthorized repair or maintenance. A few device components (e.g., electrolytic capacitor) require regular replacement. The average lifespan varies, so periodic checking is recommended.
-
Page 6: Speed Dome Overview
ECAMIP701·Quick Start Guide 1 Overview 1.1 Speed Dome Overview The network speed dome has three types: ⚫ N4xxx Series ⚫ N4xxxI Series (IR) ⚫ N5xxxI Series (IR) Note: The figures below are for reference only, refer to the actual product as the standard. 1.1.1 Overview of N4xxx Series Speed Dome Figure 1-1 Overview of N4xxx Series Speed Dome... - Page 7 ECAMIP701·Quick Start Guide 1.1.2 Overview of N4xxxI Series (IR) Speed Dome Figure 1-2 Overview of N4xxxI Series (IR) Speed Dome 1.1.3 Overview of N5xxxI Series (IR) Speed Dome Figure 1-3 Overview of N5xxxI Series (IR) Speed Dome...
-
Page 8: Cable Interfaces
ECAMIP701·Quick Start Guide 1.2 Cable Interfaces The cable interfaces of the speed dome are shown in Figure 1-4. The cables are distinguished by different colors. Refer to the labels attached on the cables for identification. Notes: ⚫ The cables vary depending on different speed dome models. ⚫... -
Page 9: Installation
ECAMIP701·Quick Start Guide 2 Installation Before you start: Check the package contents and make sure that the device in the package is in good condition and all the assembly parts are included. Notes: ⚫ Do not touch the bubble directly by hand. The image blurs otherwise. ⚫... - Page 10 ECAMIP701·Quick Start Guide Figure 2-2 Disassemble the Speed Dome 2. Install the memory card. Figure 2-3 Memory Card Slot 3. Drill screw holes in the ceiling. 1) Attach the drill template to the ceiling where you want to install the speed dome.
- Page 11 ECAMIP701·Quick Start Guide Toggle Bolt Holes Figure 2-4 Toggle Bolt Holes 3) Rotate the bolts through the screw holes. 4) Install the toggles back as shown in Figure 2-5. Figure 2-5 Install the Toggle Bolts 5. Install the speed dome to the ceiling. 1) Align the toggle bolts with the screw holes on the ceiling.
-
Page 12: Wall Mounting
ECAMIP701·Quick Start Guide 4) Secure the bubble to the speed dome with three screws as shown in Figure 2-7. Figure 2-7 Secure the Bubble 6. Route the cables through the ceiling. 7. Remove the protective film on the bubble after the installation is finished. 2.2 Installing N4xxxI Series (IR) Speed Dome 2.2.1 Wall Mounting Notes:... - Page 13 ECAMIP701·Quick Start Guide Figure 2-8 Memory Card Slot 3) Install the rear cover back and tighten the lock screws. 2. Install the bracket. 1) Get the bracket and screws from the packing box as shown in Figure 2-9. Figure 2-9 Wall Mounting Bracket 2) Drill four screw holes in the wall according to the holes on the bracket, and then insert four M8 expansion screws into the mounting holes.
-
Page 14: In-Ceiling Mounting
ECAMIP701·Quick Start Guide Figure 2-11 Safety Rope 2) Route the cables through the bracket and connect the corresponding cables. 3) Loosen the lock screws on the bracket. 4) Align the speed dome with bracket and rotate it to the bracket tightly. 5) Tighten the two lock screws with the wrench to secure the speed dome and the bracket. - Page 15 ECAMIP701·Quick Start Guide Steps: 1. Install the memory card. Note: Refer to step 1 in Section 2.2.1 Wall Mounting. 2. Drill screw holes in the ceiling. 1) Attach the drill template to the ceiling where you want to install the speed dome.
- Page 16 ECAMIP701·Quick Start Guide Figure 2-14 Push to the Mounting Hole 3) Rotate the screws clockwise and the toggle will rotate down to secure the speed dome to the ceiling. Fix the locks on the ceiling. Fix the locks on the Rotate the screws ceiling clockwise...
- Page 17 ECAMIP701·Quick Start Guide 7. Remove the protective film on the bubble after the installation is finished. 2.3 Installing N5xxxI Series (IR) Speed Dome Notes: ⚫ Refer to Section 2.2.1 Wall Mounting for wall mounting steps for N5xxxI series (IR) speed dome. ⚫...
-
Page 18: Setting The Speed Dome Over The Lan
ECAMIP701·Quick Start Guide 3 Setting the Speed Dome over the LAN Notes: ⚫ You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, strengthen your own protection. If the product does not work properly, contact with your dealer or the nearest service center. -
Page 19: Activation Via Web Browser
ECAMIP701·Quick Start Guide Activation via web browser, activation via SADP, and activation via client software are supported. We will take activation via SADP software and activation via web browser as examples to introduce the speed dome activation. 3.2.1 Activation via Web Browser Steps: 1. - Page 20 ECAMIP701·Quick Start Guide Get the SADP software from the supplied disk or the official website and install the SADP according to the prompts. Follow the steps to activate the speed dome. Steps: 1. Run the SADP software to search the online devices. 2.
-
Page 21: Modifying The Ip Address
ECAMIP701·Quick Start Guide 3.3 Modifying the IP Address Purpose: To view and configure the speed dome via LAN (Local Area Network), you need to connect the network speed dome in the same subnet with your PC. Use the SADP software or client software to search and change the IP address of the device. -
Page 22: Accessing Via Web Browser
ECAMIP701·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version/Vista/Win7/Server 2003/Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024 × 768 resolution or higher Web Browser: Internet Explorer 8 to 11, Google Chrome 31 to 44, and Mozilla Firefox 30 to 51 Steps:... - Page 23 ECAMIP701·Quick Start Guide Figure 4-2 Download Plug-in 6. Reopen the web browser after the installation of the plug-in and repeat the above step 2 to step 4 to login. Note: For detailed instructions of further configuration, refer to the user manual of network speed dome.
-
Page 24: Operating Via Guarding Vision App
ECAMIP701·Quick Start Guide 5 Operating via Guarding Vision App Purpose: Guarding Vision is an application for mobile devices. With the App, you can view live image of the speed dome, receive alarm notification and so on. Note: Guarding Vision service is not supported by certain speed dome models. 5.1 Enable Guarding Vision Service on Speed Dome Purpose: Guarding Vision service should be enabled on your speed dome before using the... -
Page 25: Guarding Vision Setup
ECAMIP701·Quick Start Guide Note: The verification code is required when you add the speed dome to Guarding Vision app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. 5.1.2 Enable Guarding Vision Service via Web Browser Before you start: You need to activate the speed dome before enabling the service. - Page 26 ECAMIP701·Quick Start Guide 5.3 Adding Speed Dome to Guarding Vision Before you start: You need to enable the Guarding Vision service on speed dome before adding it to your Guarding Vision account. Refer to Section 5.1 Enable Guarding Vision Service on Speed Dome.
-
Page 27: Initializing The Memory Card
ECAMIP701·Quick Start Guide Note: For detailed information, refer to the user manual of the Guarding Vision app. 5.4 Initializing the Memory Card Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. - Page 28 Made in PRC Imported by Velleman Group nv Legen Heirweg 33, 9890 Gavere, Belgium www.velleman.eu...
