Sinclair SDV5 Series Service Manual

Full dc inverter systems
Hide thumbs Also See for SDV5 Series:
Table of Contents

Advertisement

Quick Links

INDOOR HIGH STATIC PRESSURE DUCT UNITS SDV5-xxDHA
C O M M E R C I A L A I R C O N D I T I O N E R S S D V 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDV5 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sinclair SDV5 Series

Summary of Contents for Sinclair SDV5 Series

  • Page 1 INDOOR HIGH STATIC PRESSURE DUCT UNITS SDV5-xxDHA C O M M E R C I A L A I R C O N D I T I O N E R S S D V 5...

  • Page 2: Important Note

    Original instructions IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
  • Page 3 High Static Pressure Duct 1 Specifications ..................4 2 Dimensions ..................... 7 3 Unit Placement ..................10 4 Piping Diagrams ..................11 5 Wiring Diagrams ..................12 6 Fan Performance ................... 15 7 Capacity Tables ..................18 8 Electrical Characteristics ................ 28 9 Sound Levels ..................

  • Page 4: Specifications

    1 Specifications SDV5-71DHA / SDV5-80DHA / SDV5-90DHA Table 1.1: SDV5-71,80,90DHA specifications Model name SDV5-71DHA SDV5-80DHA SDV5-90DHA Power supply 1-phase, 220-240V, 50Hz Capacity Cooling kBut/h 24.2 27.3 30.7 Input Capacity Heating kBut/h 27.3 30.7 34.1 Input Model WZDK750-38G-W WZDK750-38G-W WZDK750-38G-W Type Fan motor Brand Panasonic/ Welling...
  • Page 5 SDV5-112DHA / SDV5-140DHA / SDV5-160DHA Table 1.2: SDV5-112,140,160DHA specifications Model name SDV5-112DHA SDV5-140DHA SDV5-160DHA Power supply 1-phase, 220-240V, 50Hz 11.2 Capacity Cooling kBut/h 38.2 47.8 54.6 Input 12.5 Capacity Heating kBut/h 42.7 54.6 Input Model WZDK750-38G-W WZDK750-38GS-W WZDK750-38GS-W Type Brand Panasonic/ Welling Fan motor 1110/1070/1010/970/...
  • Page 6 SDV5-200DHA / SDV5-250DHA / SDV5-280DHA Table 1.3: SDV5-200,250,280DHA specifications Model name SDV5-200DHA SDV5-250DHA SDV5-280DHA Power supply 1-phase, 220-240V, 50Hz Capacity Cooling kBut/h 68.2 85.3 95.5 Input 1200 22.5 31.5 Capacity Heating kBut/h 76.8 88.7 107.5 Input 1200 Model ZKSN-920-8-12 ZKSN-920-8-12 ZKSN-920-8-12 Type Fan motor...

  • Page 7: Unit Dimensions

    2 Dimensions 2.1 Unit Dimensions SDV5-71DHA / SDV5-80DHA / SDV5-90DHA / SDV5-112DHA Figure 2.1: SDV5-71,80,90,112DHA dimensions (unit: mm) 201806...
  • Page 8 SDV5-140DHA / SDV5-160DHA Figure 2.2: SDV5-140,160DHA dimensions (unit: mm) 201806...
  • Page 9 SDV5-200DHA / SDV5-250DHA / SDV5-280DHA Figure 2.3:SDV5-200,250,280DHA dimensions (unit: mm) 201806...

  • Page 10: Unit Placement

    3 Unit Placement 3.1 Placement Considerations Unit placement should take account of the following considerations:  Units should not be installed in the following locations:  Where exposure to direct radiation from a high-temperature heat source or to interference from a source of electromagnetic radiation may occur.

  • Page 11: Piping Diagrams

    4 Piping Diagrams Figure 4.1: piping diagram Legend motor Indoor ambient temperature sensor Indoor heat exchanger mid-point temperature sensor Indoor heat exchanger outlet temperature sensor flare nut gas side heat exchanger flare nut liquid side 201806...
  • Page 12   Wiring Dia grams  Figur re 5.1:  SDV5-71,80,90,112,140,160DHA Duct wiring diagram       CN22 CN15 CN17 CN19 CN14 CN21 White reen ellow     12  01806 ...
  • Page 13 SDV5-200,250,2 80DHA       Figur re 5.2:         SDV5-200,250, 280DHA wiring diagram CN15 CN19 CN14 CN17 Blue White Black Green Yellow   2018 806  13 ...
  • Page 14  Notes for installers and service engineers Caution  All installation, servicing and maintenance must be carried out by competent and suitably qualified, certified and accredited professionals and in accordance with all applicable legislation.  Units should be grounded in accordance with all applicable legislation. Metal and other conductive components should be insulated in accordance with all applicable legislation.

  • Page 15: Fan Performance

    6 Fan Performance Figure 6.1: SDV5-71,80DHA fan performance 200Pa 190Pa 180Pa 170Pa 160Pa 150Pa 140Pa 130Pa 120Pa 110Pa 100Pa(default) 90Pa 80Pa 70Pa 60Pa 50Pa 30Pa 1150 1200 1250 1300 1350 Air flow (m Figure 6.2: SDV5-90DHA fan performance 200Pa 190Pa 180Pa 170Pa 160Pa...
  • Page 16 Figure 6.3: SDV5-112DHA fan performance 200Pa 190Pa 180Pa 170Pa 160Pa 150Pa 140Pa 130Pa 120Pa 110Pa 100Pa(default) 90Pa 80Pa 70Pa 60Pa 50Pa 30Pa 1340 1390 1440 1490 1540 1590 1640 1690 1740 1790 1840 1890 Air flow (m Figure 6.4: SDV5-140DHA fan performance 200Pa 190Pa 180Pa...
  • Page 17 Figure 6.5: SDV5-160DHA fan performance 200Pa 190Pa 180Pa 170Pa 160Pa 150Pa 140Pa 130Pa 120Pa 110Pa 100Pa(default) 90Pa 80Pa 70Pa 60Pa 50Pa 30Pa 1870 1920 1970 2020 2070 2120 2170 2220 2270 2320 2370 2420 2470 2520 2570 2620 2670 Air flow (m Figure 6.6: SDV5-200,250,280DHA fan performance 250Pa 230Pa...

  • Page 18: Capacity Tables

    7 Capacity Tables 7.1 Cooling Capacity Table Table 7.1: High Static Pressure Duct cooling capacity Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 12.0 14.0 16.0 18.0 20.0 21.0 23.0 25.0...
  • Page 19 Table 7.1: High Static Pressure Duct cooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 10.7 11.7 12.0 10.7 11.5 14.0 10.7 11.4 16.0 10.7 11.3 18.0 10.7 11.0...
  • Page 20 Table 7.1: High Static Pressure Duct cooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 11.3 13.2 10.4 14.0 10.6 14.8 10.6 16.7 11.0 18.2 11.0 12.0 11.3 13.2...
  • Page 21 Table 7.1: High Static Pressure Duct cooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 13.8 12.1 16.2 13.3 18.8 14.8 20.0 15.1 21.2 15.1 23.8 15.7 26.0 15.7...
  • Page 22 Table 7.1: High Static Pressure Duct cooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 19.3 16.9 22.7 18.6 26.3 20.8 28.0 21.2 29.7 21.2 33.3 22.0 36.4 22.0...
  • Page 23 7.2 Heating Capacity Table Table 7.2: High Static Pressure Duct heating capacity Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 4.48 4.48 4.48 4.48 4.48 4.48 -18.8 4.80 4.80 4.80 4.80 4.80 4.80 -16.7 5.04 5.04 5.04 5.04 5.04...
  • Page 24 Table 7.2: High Static Pressure Duct heating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 5.60 5.60 5.60 5.60 5.60 5.60 -18.8 6.00 6.00 6.00 6.00 6.00 6.00 -16.7 6.30 6.30 6.30 6.30 6.30 6.30 -14.7 6.50...
  • Page 25 Table 7.2: High Static Pressure Duct heating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 8.96 8.96 8.96 8.96 8.96 8.96 -18.8 9.60 9.60 9.60 9.60 9.60 9.60 -16.7 10.08 10.08 10.08 10.08 10.08 10.08 -14.7 10.40...
  • Page 26 Table 7.2: High Static Pressure Duct heating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 12.60 12.60 12.60 12.60 12.60 12.60 -18.8 13.50 13.50 13.50 13.50 13.50 13.50 -16.7 14.18 14.18 14.18 14.18 14.18 14.18 -14.7 14.63...
  • Page 27 Table 7.2: High Static Pressure Duct heating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 17.64 17.64 17.64 17.64 17.64 17.64 -18.8 18.90 18.90 18.90 18.90 18.90 18.90 -16.7 19.85 19.85 19.85 19.85 19.85 19.85 -14.7 20.48...

  • Page 28: Electrical Characteristics

    8 Electrical Characteristics Table 8.1: High Static Pressure Duct electrical characteristics Power supply Indoor fan motors Model name Rated motor Volts Min. volts Max. volts output (kW) MI2-71T1DN1 220-240 0.15 MI2-80T1DN1 220-240 0.15 MI2-90T1DN1 220-240 0.18 MI2-112T1DN1 220-240 0.31 MI2-140T1DN1 220-240 0.34 MI2-160T1DN1...

  • Page 29: Sound Levels

    9 Sound Levels 9.1 Overall Figure 9.1: High Static Pressure Duct sound pressure level Table 9.1: High Static Pressure Duct sound pressure levels measurement Sound pressure levels dB(A) Model name SDV5-71DHA SDV5-80DHA SDV5-90DHA SDV5-112DHA SDV5-140DHA SDV5-160DHA SDV5-200DHA SDV5-250DHA SDV5-280DHA Notes: Sound pressure levels are measured 1.4m below the unit in a semi-anechoic chamber.
  • Page 30 Figure 9.4: SDV5-112DHA octave band levels Figure 9.5: SDV5-140DHA octave band levels NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 125 250 500 1000 2000 4000 8000 500 1000 2000 4000 8000 Octave band center frequency (Hz) Octave band center frequency (Hz)
  • Page 31 HIGH STATIC PRESSURE DUCT UNITS SDV5-71-280DHA C O M M E R C I A L A I R C O N D I T I O N E R S S D V 5...
  • Page 32 SDV5-71DHA...
  • Page 33 Description Part Code Note Qty Price Code MODEL: SDV5-71DHA HIGH STATIC PRESSURE DUCT UNIT E-Part box cover 12226000000009 E-part box assembly 17226000002934 Reactor 17400306000070 Indoor unit main control board 17126000003647 17400401001516 Wire joint Wire joint 17400401000156 Pipe temperature sensor 11201007000025 Pipe temperature sensor assemblies 11201007000030 Evaporator ass'y...
  • Page 34 SDV5-80DHA...
  • Page 35 Description Part Code Note Qty Price Code MODEL: SDV5-80DHA HIGH STATIC PRESSURE DUCT UNIT E-Part box cover 12226000000009 E-part box assembly 17226000002934 Reactor 17400306000070 Indoor unit main control board 17126000003647 17400401001516 Wire joint Wire joint 17400401000156 Pipe temperature sensor 11201007000025 Pipe temperature sensor assemblies 11201007000030 Evaporator ass'y...
  • Page 36 SDV5-90DHA...
  • Page 37 Description Part Code Note Qty Price Code MODEL: SDV5-90DHA HIGH STATIC PRESSURE DUCT UNIT E-Part box cover 12226000000009 E-part box assembly 17226000002774 Indoor unit main control board 17126000003317 Reactance 17400306000163 17127000006656 Radiator Components 2.3.1 rectifier bridge 11201418000014 2.3.2 Module board assembly 17127000006679 Wire joint 17400401001516...
  • Page 38 SDV5-112DHA...
  • Page 39 Description Part Code Note Qty Price Code MODEL: SDV5-112DHA HIGH STATIC PRESSURE DUCT UNIT E-Part box cover 12226000000009 E-part box assembly 17226000002774 Indoor unit main control board 17126000003317 Reactance 17400306000163 17127000006656 Radiator Components 2.3.1 rectifier bridge 11201418000014 2.3.2 Module board assembly 17127000006679 Wire joint 17400401001516...
  • Page 40 SDV5-140DHA...
  • Page 41 Description Part Code Note Qty Price Code MODEL: SDV5-140DHA HIGH STATIC PRESSURE DUCT UNIT E-Part box cover 12226000000009 E-part box assembly 17226000002659 Reactance 17400306000163 Radiator Components 17127000006656 2.2.1 17127000006679 Module board assembly 2.2.2 Radiator 11203803002876 2.2.3 rectifier bridge 11201418000014 Indoor unit main control board 17126000003317 Wire joint 17400401001516...
  • Page 42 SDV5-160DHA...
  • Page 43 Description Part Code Note Qty Price Code MODEL: SDV5-160DHA HIGH STATIC PRESSURE DUCT UNIT E-Part box cover 12226000000009 E-part box assembly 17226000002659 Reactance 17400306000163 Reactance 17400306000163 17127000006656 Radiator Components Radiator Components 17127000006656 2.2.1 Module board assembly 17127000006679 2.2.1 Module board assembly 17127000006679 2.2.2 Radiator...
  • Page 44 SDV5-200DHA...
  • Page 45 Description Part Code Note Qty Price Code MODEL: SDV5-200DHA HIGH STATIC PRESSURE DUCT UNIT Electric control box cover assembly 12223000010829 E-part box assembly 17226000002663 Indoor unit main control board 17126000003320 Radiator assembly 17127000006663 2.2.1 11201418000014 rectifier bridge 2.2.2 Module board assembly 17127000006676 Reactance 17400306000785...
  • Page 46 SDV5-250DHA...
  • Page 47 Description Part Code Note Qty Price Code MODEL: SDV5-250DHA HIGH STATIC PRESSURE DUCT UNIT Electric control box cover assembly 12223000010829 E-part box assembly 17226000002663 Indoor unit main control board 17126000003320 Radiator assembly 17127000006663 2.2.1 11201418000014 rectifier bridge 2.2.2 Module board assembly 17127000006676 Reactance 17400306000785...
  • Page 48 SDV5-280DHA...
  • Page 49 Description Part Code Note Qty Price Code MODEL: SDV5-280DHA HIGH STATIC PRESSURE DUCT UNIT Electric control box cover assembly 12223000010829 E-part box assembly 17226000002663 Indoor unit main control board 17126000003320 Radiator assembly 17127000006663 2.2.1 11201418000014 rectifier bridge 2.2.2 Module board assembly 17127000006676 Reactance 17400306000785...

  • Page 50: Technical Support

    SINCLAIR CORPORATION Ltd. 1-4 Argyll St. London W1F 7LD Great Britain www.sinclair-world.com This product was manufactured in China (Made in China). REPRESENTATIVE SINCLAIR Global Group s.r.o. Purkynova 45 612 00 Brno Czech Republic TECHNICAL SUPPORT SINCLAIR Global Group s.r.o. Purkynova 45...

This manual is also suitable for:

Sdv5-71dhaSdv5-80dhaSdv5-90dhaSdv5-112dhaSdv5-140dhaSdv5-160dha ... Show all
