Stil-fit ESSENCE Assembly Instruction

Functional trainer

Assembly instruction STIL-FIT Functional Trainer

ESSENCE

PURE

Fitness I Design I Interior

Table of Contents

Need help?

Do you have a question about the ESSENCE and is the answer not in the manual?

Page 1 Assembly instruction STIL-FIT Functional Trainer ESSENCE PURE Fitness I Design I Interior...
Page 2 Important The functional trainer is already preassembled. Don‘t change the position of the pulleys and the pull out unit at the front. Please follow all steps as shown. The frame can be xed to the wall to the wall at the top- and bottom part.
Page 3 cross bar Assembly of the weight plates Remove the cross bar and the selector bar The weight plates can be slided from top on to the tubes. Start with the large plates - totally 14 plates. selector bar Note! The grooves for the sticker are at the right side. Mount the small plates Assemble the selector bar with the top plate Note: The groove with the label shows to the...
Page 4 Put on all stickers of the weight plates. Function test Stick the silver pin into the second weight plate and pull at the front unit. If the pin cannot be sticked into the selector bar smoothly the cabls are too tighten. At the left top side of the frame there is an adjusta- ble screw to adjust the length of the cable.
Page 5 Version ESSENCE with mirror front: Screw the front to the frame a the top with 2 screws using the plastic cap. Assemble the side panels with screws from the rearside. The right and left panel is identical. Assemble the handels Check if verything works smoothly.
