Costway GOPLUS SP0549 User Manual

Figure of scooter's parts
1. Compass
2. Handlebar glove
3. Handlebar
4. Brake handle
5. Lock
6. Folding pole
7. Fixation sliding sleeve of folding pole
8. Front wheel
9. Fixer of front wheel
10.Front wheel's bracket and the main part's gasket
11. Main piece of bottom plate
12.Strengthening bottom cover
13. Music box
14. Fastener of main cover's lamp belt
15. Main cover
16. Footbrake
17. handbrake
18. Rear wheel
19. Screw
20. Front axle
21. Front wheel's bearing (type:608)
22. Rear wheel's bearing
23. Rear axle
24. Tension spring
25. Spring
3
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Please give us a chance to make it right and do better！
Contact our friendly customer service department for help first.
Replacements for missing or damaged parts will be shipped ASAP!
www.costway.com

Diagram of folding

Pull the fixation
sliding sleeve
upward to fold
the scooter
Fig.1
Rotation angle
1. This bicycle is folding type,move the folding vertical rod upright upwards
before using;first press the feet brake pad downwards with hand to separate
folding fixation hook with feet brake pad (check Figure 1-1 for details);
after separation, slowly raise handlebar and fixation sliding sleeve will
move downwards automatically with the effect of spring; the sound of
"bang" means fixation has been completed and the bicycle can be use
(for the sake of safety,don't put your hands at comer while the restoration
of folding) (as shown in Figure 1) .
2.If you want to fold it back,press folding vertical rod downwards after
lifting its sliding sleeve about 25mm,when you hear the sound of "bang"
(as Figure 1-2) after tightly clasping handlebar hanger and feet brake pad,
the folding of the whole bicycle is completed; it is convenient to carry.
3. When adjusting the handlebar's height, firstly release the locking buckle
of telescopic tube ,move up and down with the marble pressed,then
adjust the telescopic tube to the ideal height,and fasten the locker of telescopic
tube.(Fig.3)
4.When adjusting the brake line, fasten the nut end of brake line on the slot
of rear wheel's hand brake sheet,and then fasten the nut . The brake
sensitivity can be adjusted by adjusting the nut on the brake line . The 2
adjusting nuts are shown in (Fig.4)
If the brake is too loose ,move the two nuts downward . Otherwise, move
them upward.
www.costway.com
USER'S MANUAL
Kid Scooter
SP0549
Follow Costway
Visit us: www.costway.com
www.costway.com
Figure 1-1 Sketch map of
loosening hanger
Figure 1-2 Sketch map of hanger
combination
Screw1
Screw2
Fig.3 Fig.4
4
Contact Us!
Do NOT return this item.
Contact our friendly customer service department for help first.
E-mail
US: cs.us@costway.com
UK: cs.uk@costway.com

Before You Start

Please read all instructions carefully.
Retain instructions for future reference.
Seperate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled
near to the area in which they will be placed in use, to avoid
moving the product unnecessarily once assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product
away from babies and children as they potentially pose a
serious choking hazard.
2
5. Dual-purpose brakes are installed on this scooter, respectively
footbrake and handbrake. In the movement,the music box installed at
the inner side of the bottom can play beautiful music,and the two sides
will emit 4-color lights, which will allow the driver beauty and fun.
6. Never allow water's immersion in the movement, otherwise the
electronic components at the bottom will be damaged.

Diagram of Brake

1. Hold the handlebar to control the direction of movement and
balance the driver's boby,and then the scooter will slide forward.
2.In order to brake or stop the scooter,step the footbrake or pull the
handbrake with your hand.
5
