WOLF PUP 8.10
HEIGHT EXTENDER
PARTS
4X
height extender blocks
2X
1/4-20 x 1" pan head machine
screws
3X
1/4-20 x 1-3/4" Phillips truss
head machine screws
2X
1/4-20 x 1-1/4" Phillips truss
machine screws
1X
3/8" x 3-1/2" hex bolt
2X
1/4-20 x 2-1/2" Phillips truss
head machine screws
3X
1/4" flat washers
3X
1/4-20 lock nut
10X
extended treadle aid tie-ups
80X
extended tie-ups
2X
extended outside treadles*
8X
extended inside treadles*
*
These parts are included in the kit for adding a height
extender. If you ordered your loom with the height
extender, these parts will arrive attached to your loom.
NOTES:
■ If you received your height extender after you received your loom, you will
need to remove the treadles to replace them with the longer height extender
treadles.
■ Wolf loom legs are called out by where they cross each other. The legs that
touch the ground at the front of the loom are called "inside" legs because they
are covered by the "outside" legs when they cross at the loom center.
■ The brake is on the right side of loom. The beater is at the front of the loom.
■ The height extender legs are labelled:
RI = right inside, RO = right outside, LI = left inside, LO = left outside.
