Roady BT Feature Guide
In-Vehicle Radio

Advertisement

loading
Need help?

Need help?

Do you have a question about the Roady BT and is the answer not in the manual?

Questions and answers

Related Manuals for Sirius XM RAdio Roady BT

Summary of Contents for Sirius XM RAdio Roady BT

  • Page 1 Roady BT Feature Guide In-Vehicle Radio...

  • Page 2: What's Included

    Introduction Roady BT Feature Guide What’s Included Display Controller Unit (Front) Display Controller Unit (Rear) Intelligent Power Adapter Display Cable Magnetic Adapter Vent Mount Dash Mount Extra Adhesive Magnetic Mount Antenna AUX Audio Cable...
  • Page 3 New for Roady BT is a magnetic mounting system for the display (DCU). A magnet is attached to the vent or dash mount using the peel-and-stick adhesive on the magnet, and then the magnet and mount are magnetically attached to a metallic area on the rear of the Roady BT display, securely holding the display in place.

  • Page 4: Specifications

    Introduction Roady BT Feature Guide Specifications Key attributes at a glance: • SiriusXM branded in-vehicle radio • Very neat installation - only a single wire solution from the Display Control Unit (DCU) to the Intelligent Power Adapter (IPA) • Antenna, and optional AUX or FM cable connections, are made to the IPA •...
  • Page 5 Introduction Roady BT Feature Guide Subscription Packages Content availability on Roady BT is based on the subscription package chosen. Available packages include: • SiriusXM All Access and SiriusXM All Access Family Friendly • SiriusXM Select and SiriusXM Select Family Friendly •...
  • Page 6 Roady BT Feature Guide Listener Interface & Navigation Roady BT features a offers an large, easy-to-read 400 x 240 pixel full color screen. Now Playing Screen The Now Playing screen is the default home screen that provides essential channel and content information while listening to SiriusXM.
  • Page 7 Listener Interface & Navigation Roady BT Feature Guide Screen Element Description Song Name of the currently playing song. Artist Artist for the currently playing song. Favorite Bank and Indicates the bank and favorite number for the currently tuned Number favorite channel.
  • Page 8 Listener Interface & Navigation Roady BT Feature Guide Display Control Unit Buttons The Roady BT buttons are similar to the Onyx EZR product, and provide tactile feedback when pressed. The following table describes the actions of the buttons. Button Action...
  • Page 9 Listener Interface & Navigation Roady BT Feature Guide Button Action Result Press to skip back to the beginning of the song/ Press segment. Rewind Press & Hold Press and hold to continuously skip back. Press to pause playing channel/Press to resume Press playing channel.

  • Page 10: Feature Summary

    Feature Summary Roady BT Feature Guide Single Wire Connection to Display. The display for Roady BT features a single wire connection which eliminates the need for a vehicle dock. The antenna cable (and the AUX cable or FM cable, if used) connect to the Cigarette Lighter Adapter.
  • Page 11 The screen-by-screen guide takes the listener through the steps of subscribing the radio for the SiriusXM service. The guide is initially offered automatically when Roady BT is turned on and it detects it is not authorized for the SiriusXM service (typically a newly purchased radio).
  • Page 12 Feature Summary Roady BT Feature Guide Software Update. Roady BT can be updated with new software when it becomes available. The Display Control Unit (DCU) and Cigarette Lighter Adapter (CLA) software, and Module Firmware can be updated. The software update process consists of downloading the software update file to a PC from the SiriusXM product support page and then copying the software update to the DCU via a USB cable.
  • Page 13 30-60 minutes, depending upon they type of content and how long Roady BT has been powered on. When Roady BT is playing behind live, a replay timeline is shown indicating the length of the replay buffer, and the current play point behind the live broadcast.
  • Page 14 Feature Summary Roady BT Feature Guide Smart Favorites. Favorites provide for easy tuning of channels which have been saved as favorites. A favorite is saved by pressing and holding a number button, and tuned by pressing the number button. There is also a virtual category named Favorites which shows what is currently playing on each favorite channel.
  • Page 15 Feature Summary Roady BT Feature Guide TuneStart. TuneStart plays a song from the beginning when a qualified music channel is tuned. The TuneStart icon is briefly displayed as the song begins playing. TuneStart can be disabled if not desired. Jump. The Jump button facilitates jumping between the currently tuned channel and the immediate previously tuned channel.
  • Page 16 Direct Tune. Showing and hiding of channels are managed through Menu settings. Low Power Mode. Roady BT can enter a low power mode when turned off if power to the Cigarette Lighter Adapter is maintained. The low power mode feature provides a fast on when the radio is turned on again.
  • Page 17 Feature Summary Roady BT Feature Guide Night Comfort Mode. When Roady BT is set to night brightness, Night Comfort mode can turn off the display screen after a selected period of inactivity, 5, 15. 30, or 60 minutes. The radio buttons remain lit when in Night Comfort mode, and when a button is pressed or an alert occurs, the display screen is turned back on.
  • Page 18 Feature Summary Roady BT Feature Guide Audio Connection Indicator. The Now Playing screen has an audio connection indicator showing the type of audio connection selected (Bluetooth, AUX, or FM), and also if there is a current audio connection. The Audio connection icon is blue when there is an audio connection, and gray when...

  • Page 19: Fcc & Ic Statements

    FCC & IC Statements Roady BT Feature Guide The user is cautioned that changes or modifications not expressly approved by Sirius XM Radio Inc. can void the user’s authority to operate this device. This device complies with Part 15 of the FCC Rules.
  • Page 20 ) except in compliance with applicable export laws, rules and regulations. The user of this or any other software contained in a Sirius XM Radio Inc is explicitly prohibited from attempting to copy, decompile, reverse engineer, hack, manipulate or disassemble the object code, or in any other way convert the object code into human-readable form.
