- Page 1 User Manual TPUH632 18G HDMI Extender All Rights Reserved Version: TPUH632_2019V1.1...
- Page 2 18G HDMI Extender Statement Thanks for choosing this product, please read this user manual carefully before using this product. The functions described in this version are updated till April, 2019. In the constant effort to improve our product, we reserve the right to make functions or parameters changes without notice or obligation.
- Page 3 18G HDMI Extender Product Introduction Thanks for choosing the 18G HDMI Extender which consists a transmitter and a receiver. The extender adopts DSC compression technology to extend 4K@60Hz 4:4:4 HDMI video to distance up to 40 meters (131 feet) and 1080p@60Hz video to distances up to 70 meters (230 feet) over a single CATx cable.
- Page 4 18G HDMI Extender Transmitter Panel Description HDCP Link HDMI In HDBT Out HDMI In IR In IR Out DC 24V 1 2 3 4 Power LED: The LED illuminates green when power is applied and is off when no power is present. HDCP LED: The LED illuminates blue when there is HDMI video traffic with HDCP.
- Page 5 18G HDMI Extender Receiver Panel Description HDBT I IR Out DC 24V HDCP Link HDMI Out HDMI Out IR In 1 2 3 4 Power LED: The LED illuminates green when power is applied and is off when no power is present. HDCP LED: The LED illuminates blue when there is HDMI video traffic with HDCP.
- Page 6 18G HDMI Extender Technical Specification TPUH632T Input (1) HDMI Input Connector (1) Type-A female HDMI Output (1) HDBT Output Connector (1) RJ45 Control (1) RS232, (1) IR In (1) IR Out, Control Connector (1) 3-pin terminal block, (2) 3.5mm mini jacks TPUH632R Input (1) HDBT...
- Page 7 18G HDMI Extender System Connection The following diagram illustrates the typical input and output connection of the extender: CATx: 4K 40m,1080P 70m HDMI: RS232: Power: Transmitter Receiver IR Emitter IR Receiver IR Emitter IR Recevier Blu-Ray TV Remote Remote 4K Blu-Ray Laptop HDTV...
