Walker Edison W48FPCR Assembly Instructions Manual
Hide thumbs
Also See for W48FPCR:
- Assembly instructions manual (18 pages) ,
- Assembly instructions manual (34 pages) ,
- Assembly instructions manual (18 pages)
Advertisement
Quick Links
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Walker Edison W48FPCR
Summary of Contents for Walker Edison W48FPCR
- Page 1 Revised 07/2016...
- Page 5 Insert the cam bolts (C) and door stopper (F) into the top panel (1) by using screws (G). Insert the wooden dowel (A) to the bottom panel (2). Insert the cam bolts (C) to the front panel (10,11,13,15,16). Insert the wooden dowel (B) to the front panel (10)(11) and wooden dowel (A) to middle panel (5).
- Page 6 Insert the wooden dowel (A) into the side panel (3,4,6,7). Insert the cam bolts (C) into the side panel (3,4,6,7) and front panel (8)(9). Attach the side panel (3)(4) to the bottom panel (5) and secure it with the cam locks (D).
- Page 7 Attach the bottom panel (2) to the side panel (3)(4) and secure it with screw (H) and wrench (W). Attach the support slats (12) to the front panel (10)(11) and secure it by using screw (S).
- Page 8 Attach the front panel (10)(11) to the side panel (3)(4) and secure it by using cam locks (D). Attach the front panel (13)(15)(16) to the bottom panel (2) and middle panel (5) by using cam locks (D).
- Page 9 Attach the front panel (8)(9) to the side panel (6)(7) and secure it by using cam locks (E). Attach the side panel (8)(9) to the bottom panel (2) and secure it by using cam locks (D).
- Page 10 Attach the side panel (6)(7) to the bottom panel (2) and secure it by using screw (H) and wrench (W). Insert the back panel (21) into the slot of side panel (6)(7). Place the top panel (1) on top of the side panel (6)(7), support panel (3)(4) and secure it by using cam locks (D).
- Page 11 Use stickers (Y) to cover the cam locks. Secure the back panel (21) by using the plastic wedge (T) and screw (U).Put the fireplace insert (Z) carefully into the stand and secure it by using screw (V).
- Page 12 Insert the cam bolts (C) to the bottom panel (2) and attach the support panel (14) to the bottom panel (2) by using cam locks (D) to secure it. Use stickers (Y) to cover the cam locks.
- Page 13 Insert the shelf support pin (R) into the stand and place the shelf (17)(18) on top. Attach the metal piece (M) to the glass doors (19)(20) and secure it by using screw (J). Attach the door knob (K) to the glass doors (19)(20) and secure it by using screw (L).
- Page 14 Attach the door hinge (P)(N) to the glass doors (19)(20) and secure it by using screw (J). Insert the plastic pivot (Q) as shown as the diagram.
- Page 15 Insert the door hinge (P)(N) into the plastic pivot (Q). Insert the doors (19)(20) as shown in diagram and secure it with screw (J).
