TABLE OF CONTENTS
1 Safety Precautions----------------------------------------------- 3
2 Specifications ----------------------------------------------------- 5
3 Features ------------------------------------------------------------- 9
4 Location of Controls and Components ------------------10
4.1. Indoor Unit--------------------------------------------------10
4.2. Outdoor Unit -----------------------------------------------10
4.3. Remote Control -------------------------------------------10
Indoor Unit
CS-PC12MKF CU-PC12MKF
CS-PC18MKF CU-PC18MKF
CS-PC24MKF CU-PC24MKF
PAGE
5 Dimensions ------------------------------------------------------- 11
5.1. Indoor Unit ------------------------------------------------- 11
5.2. Outdoor Unit----------------------------------------------- 13
6 Refrigeration Cycle Diagram -------------------------------- 15
7 Block Diagram --------------------------------------------------- 16
7.1. CS-PC12MKF--------------------------------------------- 16
7.2. CS-PC18MKF CS-PC24MKF ------------------------ 17
