  • Page 2 Product Information Overview The Conquip Manhole Box is a simple to assemble, two sided trench lining support system designed to be installed by an excavator using the ‘dig and push’ technique, or by simply carrying out the excavation and then lowering each box into place.

  • Page 3: Specification

    (Min - Max) (Min - Max) TL103-00011 1565-3465mm 2,766kg 80.96 kN/m TL103-00012 1565-3465mm 1,592kg 80.96 kN/m TL103-00007 1565-3465mm 3,266kg 57.83 kN/m TL103-00008 1565-3465mm 1,872kg 57.83 kN/m TL103-00009 1565-3465mm 3,516kg 45.43 kN/m TL103-00010 1565-3465mm 1,972kg 45.43 kN/m User Guide - Manhole Box...

  • Page 4: Parts Diagram

    Parts Diagram Parts Diagram Manhole Base Box Manhole Extension Box NOTE: These parts are for this model, they may differ for previous versions. Please contact Conquip with any queries. Item Number Description Quantity NOTE: These parts are for this model, they may differ for previous versions. Please contact Conquip with any queries.

  • Page 5: Usage Instructions

    8. Connect the two free legs of the lifting sling to the upper lifting points of the other panel before lifting the box into the trench. User Guide - Manhole Box...
  • Page 6 4. Once in place, insert a 40mm Ø pin through the panel soldier and connector bracket. Secure with an R-clip. User Guide - Manhole Box...

  • Page 7: Important Installation Notes

    11. To secure the Manhole Box, add Conquip Edge Protection panels. Complete extension box. the final ‘dig and push’ until the top of the Manhole Box is at ground level. Ensure the force is applied to the edge of the box panels, not the Edge 12.
  • Page 8 15. Lift the extension box away from the excavation and lay on timber bearers. 16. Wind loading can cause instability if boxes are left upright. Conquip recommend connecting a lifting sling to the top lifting points of the extension box and lowering it on its side.

  • Page 9: Safety Instructions

    Your risk assessment will determine the correct Personal Protective Equipment (PPE) for the task you are doing. You must use it. Conquip recommends that you should wear: • This equipment weighs more than 25kg. Do not lift or manhandle without machine assistance.
  • Page 10 If any third-party modifications or alterations, involving drilling, welding, cutting or distortion of materials in any form, are to be carried out on the product, Conquip Engineering Group must provide full written approval prior to the work being carried out.

  • Page 11: Important Notes

    Important Notes • This User Guide is for this Conquip product only. • Any movements of the product must be thoroughly planned before the work commences to identify potential hazards and assess risk. • All personnel involved in lifting and transportation of this product must have read this User Guide and must be properly briefed.
