Aiwa HV-FX8000 Service Manual

Hide thumbs Also See for HV-FX8000:
Table of Contents

Advertisement

Quick Links

Download this manual
All manuals and user guides at all-guides.com
HV-FX8000
U
REW/
/F FWD
DA 4 HEAD/AUTO HEAD CLEANING/DIGITAL AUTO TRACKING
PLAY
REC/ITR PAUSE/
STILL
STOP
ONE TOUCH PLAYBACK
SERVICE MANUAL
BASIC TAPE MECHANISM : D-33
STEREO VIDEO CASSETTE RECORDER
Replace this Service Manual with "Revision Publishing" when it is issued.
S/M Code No. 09-995-330-9T1

Advertisement

Table of Contents
loading

Related Manuals for Aiwa HV-FX8000

Summary of Contents for Aiwa HV-FX8000

  • Page 1 All manuals and user guides at all-guides.com HV-FX8000 REW/ /F FWD DA 4 HEAD/AUTO HEAD CLEANING/DIGITAL AUTO TRACKING PLAY REC/ITR PAUSE/ STILL STOP ONE TOUCH PLAYBACK SERVICE MANUAL BASIC TAPE MECHANISM : D-33 STEREO VIDEO CASSETTE RECORDER Replace this Service Manual with "Revision Publishing" when it is issued.

  • Page 2: Specifications

    All manuals and user guides at all-guides.com SPECIFICATIONS Video recording system Audio track 3 tracks (Hi-Fi sound 2 tracks, Normal sound Rotary 2 head herical scanning system 1 track) Video head Double azimuth 4 head Audio input -6 dBs, 47 kohm Tuner system Frequency synthesized tuner Audio output...

  • Page 3: Electrical Main Parts List

    All manuals and user guides at all-guides.com ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C324 87-015-681-080 CAP,E 10-16V C327 87-010-403-040 CAP,E 3.3-50V SI-SO2-104-00A IC,CXA2104S C328 87-015-681-080 CAP,E 10-16V SI-MA3-328-00A IC,AN3328S C330 87-010-402-040 CAP,E 2.2-50V SI-MA3-664-00A...

  • Page 4: Transistor Illustration

    All manuals and user guides at all-guides.com REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C854 87-015-694-080 CAP,E 0.47-50V R102 S6-140-07K-000 RES,CEM 3.3-2W C855 87-015-698-080 CAP,E 4.7M-50V R104 SR-S33-02K-619 RES,M/F 33K-2W C856 87-015-681-080 CAP,E 10-16V R105 SR-S12-00J-619 RES,M/F 120-1W C857...
  • Page 5 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM-1 (POWER SECTION) A MAIN(POWER SECTION)C.B T101 TRANS D109 L104 D151 D152 D153 R102 RU3YXLF 1N4003 1N4003 1N4003 3.3(2W) 12V(CAP) BD101 C105 R104 Q151 S1WBA60 0.01/630V R103 33K(2W) C120 C121 KTD1414 SYSCON/ C111 15.0 220K...
  • Page 6 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM-2 (AUDIO/ VIDEO SECTION) A MAIN (AUDIO/VIDEO SECTION)C.B 5.1VA 5.1VD L305 POWER SECTION L306 C342 C343 47/16 0.01 C346 C371 IC301 680P HA118217NF AUDIO/VIDEO PROCESS R329 Hi-Fi PB B Hi-Fi C339 1.5K X301 Hi-Fi REC C337...
  • Page 7 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM-3 (SYSTEM CONTROL/SERVO/OSD SECTION) A MAIN (SYSTEM CONTROL/SERVO/OSD SECTION)C.B R5A4 12V(DRUM) IC502 KA3082 5.3VA PMK02 MOTOR DRIVE C5A3 IC505 DIG5F1 180P KA7542Z D5E2 1SS133 KEY RTN 1 C5A5 Hi-Fi OTPB "H" 1/50 C5A4 5.3VA 0.022...
  • Page 8 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM-4 (Hi-Fi AUDIO SECTION) IC802 AN3328S A MAIN (Hi-Fi AUDIO SECTION) C.B R838 0(-) PB ON 2.7(2.5) L804 100u 0(4) 5.1VA 10 VCC Hi-Fi REC 0(4) C843 3.4(3) C845 C841 R820 47/16 0.01 Hi-Fi RF 0.01...
  • Page 9 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM-5 (TUNER/IF SECTION) A MAIN(TUNER/IF SECTION)C.B REG9V POWER C710 5.1VD SECTION Hi-Fi MOD AUDIO SECTION AUDIO(TU) TU701 TADC-H002F TUNER VIDEO(TU) VIDEO VIDEO(LINE) DETECTOR C704 0.1/50 R703 SECTION C705 FILTER FILTER 470/6.3 2 . 8 DETECTOR L701 BLOCK...
  • Page 10 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM-6 (FRONT 1 SECTION) B FRONT 1 C.B L D 9 0 1 O T P B R 9 1 0 1 5 0 P 9 M 0 1 G N D T o A R 9 1 1 M A I N C .

  • Page 11: Wire Harness Diagram

    All manuals and user guides at all-guides.com WIRE HARNESS DIAGRAM PMD01 PMD01 D.CTL M.GND LOWER DRUM 5.3V PMC01 PCM01 P9M02 PMK01 MOTOR GND VIDEO(L2) I-LIMIT CAPSTAN CAP CTL AUDIO-L(L2) C FRONT2 C.B MOTOR AUDIO-R(L2) CAP REV "L" 5.3V KEY RTN0 P3D02 P3D02 CTL(+)

  • Page 12: Mechanical Exploded View

    All manuals and user guides at all-guides.com MECHANICAL EXPLODED VIEW 1/1...
  • Page 13 All manuals and user guides at all-guides.com MECHANICAL MAIN PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION ——— PANEL ASSY 2 S7-20R-F07-1A0 PANEL FRONT 3 S5-80R-003-2A0 DOOR CST 4 S4-426-81A-000 SPRING DOOR ——— COVER BOTTOM ——— FRAME MAIN ——— DECK ASSY 8 S9-30R-013-3A0 HOLDER DIGITRON...

  • Page 14: Mechanism Exploded View

    All manuals and user guides at all-guides.com MECHANISM EXPLODED VIEW 1/3...
  • Page 15 All manuals and user guides at all-guides.com MECHANISM MAIN PARTS LIST 1/3 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 032 S1-41R-000-2A0 CHASSIS ASSY ——— ARM F/L(R) 100 S3-01R-002-9A0 PLATE ASSY TOP 115 S9-70R-005-0A0 SPRING SWITCH 101 S8-10R-005-6A0 BRACKET SIDE(L) 116 S5-10R-002-0A0...
  • Page 16 All manuals and user guides at all-guides.com MECHANISM EXPLODED VIEW 2/3...
  • Page 17 All manuals and user guides at all-guides.com MECHANISM MAIN PARTS LIST 2/3 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 001 S7-23R-010-6C0 DRUM ASSY 021 S4-21R-000-4A0 BRAKE ASSY T 002 S6-80R-B00-04A MOTOR(MECH) 022 S5-238-33B-000 HEAD FE D33 003 S9-30R-010-8A0 HOLDER FPC(6CH) 023 S9-80R-001-0A0...
  • Page 18 All manuals and user guides at all-guides.com MECHANISM EXPLODED VIEW 3/3...
  • Page 19 All manuals and user guides at all-guides.com MECHANISM MAIN PARTS LIST 3/3 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 051 S4-00R-000-5A0 BELT CAPSTAN ——— BRACKET JOG 052 S6-80R-000-2A0 MOTOR(MECH) ——— LEVER JOG 053 S9-74R-001-8A0 GUIDE RACK F/L ———...
  • Page 20 All manuals and user guides at all-guides.com 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111 Printed in Singapore 920074...
